tesa® ACXplus 772XX is a single layer acrylic foam tape designed for automotive attachment parts. Its viscoelastic acrylic foam core achieves reliable and high bonding performance on a variety of substrates and can withstand changing environmental conditions throughout the lifetime of a vehicle.
tesa® ACXplus 772XX Base Line
Our recommendation
Get in touch
To ensure the highest performance possible, our aim is to fully understand your application (including the substrates involved) in order to provide the right product recommendation. Get in touch so we can find the right solution for you!
I agree to receive communications from tesa regarding my request and their other services.
tesa is committed to protecting and respecting your privacy, and we’ll only use your personal information to administer your account and to provide the products and services you requested from us. From time to time, we would like to contact you about our products and services, as well as other content that may be of interest to you.
You can unsubscribe from these communications at any time. For more information on how to unsubscribe, our privacy practices, and how we are committed to protecting and respecting your privacy, please review our Privacy Policy.
Facts and figures
| Product design | Construction | Liner and tabbing | Static shear resistance at heat |
|---|---|---|---|
| Single layer | Pure acrylic foam | PV31 – white film liner 1 50099 and 50699 adhesive tabbing PV34 – white film liner2 50699 adhesive tabbing PV04 – white PE coated paper liner 3 | 90 °C > 10,000 min |
- Not available for 77204
- Available for 77204 and 77208 only
- Available for 77204 only
The series
| Assortment | Thickness [mm] |
|---|---|
| tesa® 77204 | 0.4 |
| tesa® 77206 | 0.6 |
| tesa® 77208 | 0.8 |
| tesa® 77210 | 1.0 |
| tesa® 77212 | 1.2 |
Example in the series
Up to 27 N/cm
Adhesion to steel after 72 hours
tesa® 77212
Up to 12 N/cm
Adhesion to ABS after 72 hours
tesa® 77212
Up to 37 N/cm1
Adhesion to PP after 72 hours
tesa® 77212 - Using tesa® 60153 primer1
-40 to +80 °C
Temperature range
tesa® 77212
