tesa® 52307
For the mounting of very thin photopolymer plates on compressible sleeves
Product description
tesa® 52307 is specially designed for the mounting of very thin photopolymer plates (0.76mm [0.030"] or 1.14mm [0.045"]) on compressible foam sleeves in wide-web flexographic printing.
This plate mounting solution has significantly different adhesion levels on the two tape sides. As a result, the open-side adhesion is high enough to promote a secure bond to the rough surface of the compressible sleeve, while the tailored adhesion on the plate side provides an exact and stable positioning of the plate without any moving and edge lifting during the print run.
tesa® 52307 remains secure while demounting thin plates from compressible sleeves and can be removed afterwards easily and without residues.
Due to the different compressible coatings that are are available on the market (rubber, foam, PU) it is recommended to make individual application tests with tesa® 52307 before entering full production.
This plate mounting solution has significantly different adhesion levels on the two tape sides. As a result, the open-side adhesion is high enough to promote a secure bond to the rough surface of the compressible sleeve, while the tailored adhesion on the plate side provides an exact and stable positioning of the plate without any moving and edge lifting during the print run.
tesa® 52307 remains secure while demounting thin plates from compressible sleeves and can be removed afterwards easily and without residues.
Due to the different compressible coatings that are are available on the market (rubber, foam, PU) it is recommended to make individual application tests with tesa® 52307 before entering full production.
Application Fields
tesa® 52307 is specially designed for the mounting of very thin photopolymer plates (0.76mm [0.030"] or 1.14mm [0.045"] on compressible foam sleeves in wide-web flexographic printing.
Product Construction
| Backing material | PVC film |
| Type of adhesive | acrylic |
| Type of liner | glassine |
Properties / Performance Values
| Thickness category | 70 |
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
