tesa® 6940 PV3 silver glossy/ black
High-speed laser markable film
Product Features
- Marked irreversible by laser with excellent long-term legibility by the human eye or scanning devices
- High contrast and marking precision support the realization of even the smallest letters, numbers and symbols, even 2D-bar codes (data matrix, QR codes)
- Manipulation leaves visible trace (damage on information and label) to prevent re-using
Product description
tesa® 6940 PV3 Silver glossy/ black is a two-layer high-speed laser markable film with an acrylic adhesive. The brittle product construction ensures that the label is destroyed upon any attempt of removing and tampering and leaves a visible trace (damage of information and label).
Marking and cutting are achieved by laser in one step, which makes it possible to realize any desirable label variation and format using only one material. The top layer allows for high marking speed (up to 4000mm/sec.).
Product details and specifications
Product Features
- Marked irreversible by laser with excellent long-term legibility by the human eye or scanning devices
- High contrast and marking precision support the realization of even the smallest letters, numbers and symbols, even 2D-bar codes (data matrix, QR codes)
- Manipulation leaves visible trace (damage on information and label) to prevent re-using
- Just-in-time production replaces a multitude of pre-made labels and reduces storage needs
Application Fields
Used as a tamper evident identification label over the entire lifetime of a product and as a data carrier system for intelligent in-process steering.
Product Construction
| Adhesive weight | 25 g/m² |
|---|---|
| Backing material | Acrylic film |
| Thickness of tape | 110 µm |
| Type of adhesive | acrylic |
| Type of liner | coated paper |
| Weight of liner | 122 g/m² |
Product Construction
| Adhesive weight | 25 g/m² |
|---|---|
| Backing material | Acrylic film |
| Thickness of tape | 110 µm |
| Type of adhesive | acrylic |
| Type of liner | coated paper |
| Weight of liner | 122 g/m² |
Properties / Performance Values
| Shelf life time | 12 months |
|---|---|
| Ageing resistance (UV) | very good |
| Tamper evidence | yes |
| Temperature resistance short term duration | 250 °C |
| Temperature resistance long term duration | 120 °C |
| Frost resistance | -40 °C |
| Suitable laser | Nd:YAG, Yb:YAG |
| Peel off force from liner | 0,5-10 |
| Chemical resistance | very good |
| Humidity resistance | good |
Properties / Performance Values
| Shelf life time | 12 months |
|---|---|
| Ageing resistance (UV) | very good |
| Tamper evidence | yes |
| Temperature resistance short term duration | 250 °C |
| Temperature resistance long term duration | 120 °C |
| Frost resistance | -40 °C |
| Suitable laser | Nd:YAG, Yb:YAG |
| Peel off force from liner | 0,5-10 |
| Chemical resistance | very good |
| Humidity resistance | good |
Adhesion to Values
| Adhesion to steel | 1.8 N/cm |
|---|
Adhesion to Values
| Adhesion to steel | 1.8 N/cm |
|---|
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
Downloads
Download the files below for more technical details and information on this product.
