tesa® 66826
Technical properties
Elongation at break
240 %
Type of adhesive
tackified acrylic
Tensile strength
11.5 N/cm
Total thickness
300 µm
Backing material
PE foam
Colour
black
Adhesion properties
Adhesion to Steel (initial)
12.5 N/cm
Adhesion to PE (initial)
6 N/cm
Adhesion to PC (after 14 days)
15.5 N/cm
Adhesion to PMMA (after 14 days)
16.4 N/cm
Adhesion to ABS (initial)
9.2 N/cm
Adhesion to ABS (after 14 days)
11.5 N/cm
Adhesion to Aluminium (after 14 days)
12.3 N/cm
Adhesion to PC (initial)
12.4 N/cm
Adhesion to Glass (after 14 days)
13.8 N/cm
Adhesion to PE (after 14 days)
6.5 N/cm
Adhesion to Glass (initial)
13 N/cm
Adhesion to PMMA (initial)
12.9 N/cm
Adhesion to Aluminium (initial)
9.2 N/cm
Adhesion to Steel (after 14 days)
14.4 N/cm
Rating properties
Static shear resistance at 23°C
+
Humidity resistance
+
Ageing resistance (UV)
+
Temperature resistance long term
70 °C
Static shear resistance at 40°C
+
Temperature resistance short term
90 °C
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
