tesa® 67310

10µm single-sided matte black polyimide tape

Product Features
  • Thickness: 10µm
  • Ultra matte black surface with a gloss level of 2.5 %
  • Outstanding scratch and fingerprint resistance
All product features
Product description

tesa® 67310 is a matte black single-sided tape, consisting of an ultra-thin polyimide film backing and special anti-repulsion acrylic adhesive.

tesa® 67310 features:

  • Thickness: 10µm
  • Ultra matte black surface with a gloss level of 2.5 %
  • Outstanding scratch and fingerprint resistance
  • Excellent anti-repulsion properties
  • Very good chemical and temperature stability
  • Very good insulation resistance properties

Product details and specifications

Product Features

  • Thickness: 10µm
  • Ultra matte black surface with a gloss level of 2.5 %
  • Outstanding scratch and fingerprint resistance
  • Excellent anti-repulsion properties
  • Very good chemical and temperature stability
  • Very good insulation resistance properties

Application Fields

  • Ferrite and graphite sheet protection
  • NFC antenna covering
  • Fixing or wrapping applications where insulation resistance, flame retardant or high temperature is required
  • Li-battery edge wrapping
Adhesive Type acrylic
Backing material Polyimide
Color of liner transparent
Liner Type PET
Thickness of liner 50 µm
Total thickness 10 µm
Elongation at break 30 %
Dielectric breakdown voltage 1,500 V
Adhesion to Steel 1.2 N/cm
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
Downloads

Download the files below for more technical details and information on this product.

Product information_tesa® 67310_en 50.5 kB
Get in contact with us!

Contact us

Thank you for your message.

We will contact you as soon as possible.

Something went wrong. Please try again later.

Product comparison

Name of product
tesa adhesive tape layers separated showing beige top layer, transparent middle layer, and black bottom layer on white background (This text has been generated by AI)
tesa® 67310
stack of three rectangular adhesive sheets in beige and black, shown in a layered arrangement on a white background (This text has been generated by AI)
tesa® 7920
stack of three rectangular adhesive sheets in beige and black, shown in a layered arrangement on a white background (This text has been generated by AI)
tesa® 7950
tesa® 58377
stack of three rectangular adhesive sheets in beige and black, shown in a layered arrangement on a white background (This text has been generated by AI)
tesa® 7930
tesa adhesive tape layers separated showing beige top layer, transparent middle layer, and black bottom layer on white background (This text has been generated by AI)
tesa® 67350
stack of three rectangular adhesive sheets in beige and black, shown in a layered arrangement on a white background (This text has been generated by AI)
tesa® 7910
automotive-epowertrain-58346 72dpi
tesa® 58346
tesa adhesive tape layers separated showing beige top layer, transparent middle layer, and black bottom layer on white background (This text has been generated by AI)
tesa® 67320
three layered adhesive sheets with a brown base, a white middle layer, and a cream top layer slightly peeled back on a white background (This text has been generated by AI)
tesa® 66320
tesa adhesive tape layers separated showing beige top layer, transparent middle layer, and black bottom layer on white background (This text has been generated by AI)
tesa® 58356
tesa-50650-conformable-polyester-silicone-masking-tape-blue-506500000000-pr
tesa® 58344
Total thickness
10 µm
20 µm
50 µm
50
30 µm
50 µm
10 µm
90 µm
20 µm
20 µm
130
90 µm
Adhesive Type
acrylic
acrylic
acrylic
FR acrylic
acrylic
acrylic
acrylic
tackified acrylic
acrylic
acrylic
tackified acrylic
modified acrylic
Backing material
Polyimide
PET film
PET film
PET
PET film
Polyimide
PET film
PET film
Polyimide
Polyimide
PET
PET
Dielectric breakdown voltage
1,500 V
1,500 V
4,500 V
4,500 V
3,500 V
3,700 V
1,500 V
12,000 V
2,400 V
3,600 V
13,330 V
12,000 V
Temperature resistance short term
130 °C
130 °C
125 °C
130 °C
140 °C
130 °C
140 °C
140 °C
Temperature resistance long term
60 °C
60 °C
70 °C
60 °C
85 °C
60 °C
125 °C
85 °C
85 °C
125 °C
125 °C
Tensile strength
8.7 N/cm
36.7 N/cm
20 N/cm
20 N/cm
8.7 N/cm
13 N/cm
20 N/cm
165
100 N/cm
Last updated on Apr 16, 2024
