tesa® 51616

Thick PET- fleece wire harness tape for high noise reduction

Product description

tesa® 51616 is the cost efficient solution providing excellent noise reduction and a high abrasion resistance. It is for manual application on wire harnesses.

Features:

hand tearable
very high sound damping
temperature resistance 125°C/3000h
resistant to ageing
rot-proof
strong adhesion
flexible and smooth

Product details and specifications

Application Fields

tesa® 51616 is a wire harnessing tape designed for the passenger compartment, providing high noise damping.

Backing material	PET fleece
Total thickness	650 µm
Type of adhesive	rubber based

Backing material	PET fleece
Total thickness	650 µm
Type of adhesive	rubber based

Elongation at break	50 %
Tensile strength	30 N/cm
Unwind force (roll width ≤ 9mm)	12 N/roll (30 m/min)
Noise damping (LV312)	Class D
Abrasion resistance (10mm mandrel, LV312)	Class D
Minimum temperature resistance	-40 °C
Unwind force (roll width > 9mm)	12 N/roll (30 m/min)
Abrasion resistance (5mm mandrel, LV312)	Class C
Temperature resistance max	105 °C

Elongation at break	50 %
Tensile strength	30 N/cm
Unwind force (roll width ≤ 9mm)	12 N/roll (30 m/min)
Noise damping (LV312)	Class D
Abrasion resistance (10mm mandrel, LV312)	Class D
Minimum temperature resistance	-40 °C
Unwind force (roll width > 9mm)	12 N/roll (30 m/min)
Abrasion resistance (5mm mandrel, LV312)	Class C
Temperature resistance max	105 °C

Adhesion to steel	3 N/cm

Adhesion to steel	3 N/cm

Standard widths: 9, 19, 25, 32 mm
Standard lengths: 7.5 m

Most combinations of width and length are possible
Further dimensions are available upon request

Standard core diameter: 38 mm
