tesa® 66905
50µm double-sided black anti-repulsion filmic tape
Product description
tesa® 66905 is a double-sided self-adhesive tape consisting of a black PET backing and a special anti-repulsion adhesive.
tesa® 66905 features:
- Thickness: 50µm
- Excellent repulsion resistance properties
- High bonding strength and shear resistance
- Very good handling performance in converting processes
- Excellent resistance to demanding environmental conditions
Main applications
- Bonding on curved surfaces
- Mounting of bent substrates
- Antenna/FPC mounting
Technical properties
Backing material
PET film
Color
black
Total thickness
50 µm
Type of adhesive
tackified acrylic
Adhesion properties
Adhesion to Steel (after 14 days)
6.8 N/cm
Adhesion to Steel (initial)
4.5 N/cm
Rating properties
Temperature resistance short term
140 °C
Temperature resistance long term
85 °C
Static shear resistance at 23°C
++
Static shear resistance at 70°C
++
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
