tesa® 62612

1600 µm double sided PE foam tape



Product description

tesa® 62612 is a double sided PE foam tape which has been especially designed for window glazing applications. It consists of a conformable PE foam backing and a pure acrylic adhesive. tesa® 62612 is certified according to the ift guideline VE-08/1.

Product benefits:
  • High ultimate adhesion level for a secure bonding performance
  • Fully outdoor suitable: UV, water and ageing resistant
  • Low initial tack allows easy removal of the tape right after application

Main applications

Window glazing

Additional Info

Liner variants:
  • PV0 brown glassine paper (71 µm)
  • PV15 blue PE film (100 µm)

Peel Adhesion:
  • after 14 days: foam splitting on steel, aluminium, PVC, and glass

Technical properties

Elongation at break

300 %

Type of adhesive

pure acrylic

Total thickness

1600 µm

Backing material

PE foam

Color

black

Adhesion properties

Adhesion to Steel (initial)

12 N/cm

Adhesion to Aluminium (after 14 days)

19 N/cm

Adhesion to PVC (initial)

9 N/cm

Adhesion to Glass (after 14 days)

19 N/cm

Adhesion to Glass (initial)

19 N/cm

Adhesion to Aluminium (initial)

7 N/cm

Adhesion to Steel (after 14 days)

19 N/cm

Adhesion to PVC (after 14 days)

19 N/cm

Rating properties

Static shear resistance at 23°C

++

Resistance to chemicals

+

Humidity resistance

++

Tack

o

Ageing resistance (UV)

+

Temperature resistance long term

80 °C

Static shear resistance at 40°C

++

Temperature resistance short term

90 °C

tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
