tesa® 62562
50µm double sided transparent differential filmic tape
Product Features
- Thickness:50µm
- Excellent anti-repulsion performance on the low tack side
- High bonding strength on the high tack side
Product description
tesa® 62562 is a transparent, double-sided self-adhesive tape consisting of a PET backing with a special anti-repulsion adhesive on one side and a tackified acrylic adhesive on the other side.
Product details and specifications
Product Features
- Thickness:50µm
- Excellent anti-repulsion performance on the low tack side
- High bonding strength on the high tack side
- Excellent resistance to demanding environmental conditions
- Very good handling performance in converting processes
- Different color PET liner version PV55 available (transparent on low adhesion side / blue on high adhesion side)
Application Fields
Packging applications:
- Mounting of two different substrates, where one needs anti-repulsion performance and the other one needs high bonding strength, e.g. outer box wrapping, adaptor wrapping etc.
Product Construction
| Adhesive Type | tackified acrylic |
|---|---|
| Backing material | PET film |
| Color | transparent |
| Color of liner (easy release) | transparent |
| Color of liner (tight release) | blue |
| Color of liner - inside | transparent |
| Liner Type | PET film |
| Total thickness | 50 µm |
| Type of liner (easy release) | PET |
| Type of liner (tight release) | PET |
| Type of liner - inside | PET |
| Type of liner - outside | PET |
Product Construction
| Adhesive Type | tackified acrylic |
|---|---|
| Backing material | PET film |
| Color | transparent |
| Color of liner (easy release) | transparent |
| Color of liner (tight release) | blue |
| Color of liner - inside | transparent |
| Liner Type | PET film |
| Total thickness | 50 µm |
| Type of liner (easy release) | PET |
| Type of liner (tight release) | PET |
| Type of liner - inside | PET |
| Type of liner - outside | PET |
Properties / Performance Values
| Elongation at break | 50 % |
|---|---|
| Tensile strength | 20 N/cm |
| Tack | medium |
| Static shear resistance at 23°C | very good |
| Humidity resistance | very good |
| Temperature resistance short term | 200 °C |
| Ageing resistance (UV) | very good |
| Static shear resistance at 40°C | very good |
| Temperature resistance long term | 100 °C |
Properties / Performance Values
| Elongation at break | 50 % |
|---|---|
| Tensile strength | 20 N/cm |
| Tack | medium |
| Static shear resistance at 23°C | very good |
| Humidity resistance | very good |
| Temperature resistance short term | 200 °C |
| Ageing resistance (UV) | very good |
| Static shear resistance at 40°C | very good |
| Temperature resistance long term | 100 °C |
Adhesion to Values
| Adhesion to Steel (initial) | 5.1 N/cm |
|---|---|
| Adhesion to Steel (after 14 days) | 6.5 N/cm |
| Adhesion to Steel (covered side, after 14 days) | 13.8 N/cm |
| Adhesion to Steel (covered side, initial) | 11 N/cm |
Adhesion to Values
| Adhesion to Steel (initial) | 5.1 N/cm |
|---|---|
| Adhesion to Steel (after 14 days) | 6.5 N/cm |
| Adhesion to Steel (covered side, after 14 days) | 13.8 N/cm |
| Adhesion to Steel (covered side, initial) | 11 N/cm |
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
