tesa® 54190 Precision Die Cuts
High performance decorative film for Black Out Design and Permanent Protection of sensitive surfaces
Product description
The self adhesive tape consist of a black PVCfilm coated with a pure acrylic adhesive. tesa® 54190 can be applied for exterior and interior decorative purposes in the automotive industry.
It can also be applied for the permanent protection of car parts from mechanical damage and to seal holes in the car body work.
The film can be shaped when heated and can also be used on 3D-surfaces.
It can also be applied for the permanent protection of car parts from mechanical damage and to seal holes in the car body work.
The film can be shaped when heated and can also be used on 3D-surfaces.
Application Fields
tesa® 54190 is designed for exterior and interior decorative application and permanent protection around the car body. This tape has a perfect visual appearance and long lasting adhesion properties on painted surfaces.
The product is also perfectly suitable for BSR-Applications.
The product is also perfectly suitable for BSR-Applications.
Product Construction
| Elongation at break | 250 % |
| Type of adhesive | acrylic |
| Type of liner | PE-coated paper |
| Color of liner | white |
| Tensile strength | 60 N/cm |
| Weight of liner | 138 g/m² |
| Total thickness | 185 µm |
| Backing material | PVC film |
| Color | black |
Properties / Performance Values
| Abrasion resistance | good |
| Resistance to chemicals | very good |
| Scratch resistance | ++ |
| Matt surface finish | Yes |
| Temperature resistance | + |
Adhesion to Values
| Adhesion to Steel (initial) | 8.5 N/cm |
Additional Info
tesa® 54190 can be supplied individually to customer specification in various dimensions.
Under the product number tesa® 7190, the material is also available as rolls.
Under the product number tesa® 7190, the material is also available as rolls.
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
