tesa® 7190
High performance decorative film for Black Out Design and Permanent Protection of sensitive surfaces.
Product description
The self adhesive tape consist of a black PVC film coated with a pure acrylic adhesive. tesa® 7190 can be applied for exterior and interior decorative purposes in the automotive industry.The product features perfect optical appearance and long lasting adhesion properties. It can also be applied for the permanent protection of car parts from mechanical damage and to seal holes in the car body work.
The film can be shaped when heated and can also be used on 3D-surfaces.
Main applications
tesa® 7190 is designed for exterior and interior decorative application and permanent protection around the car body.This tape has a perfect visual appearance and long lasting adhesion properties on painted surfaces.
Additional Info
The material can be delivered either in roll form or as die-cuts.The special paper liner guarantees an accurate die-cutting process and perfect handling during application.
Technical properties
Elongation at break
250 %
Type of adhesive
acrylic
Adhesion to Steel (initial)
8.5 N/cm
Type of liner
PE-coated paper
Colour of liner
white
Tensile strength
60 N/cm
Weight of liner
138 g/m²
Total thickness
185 µm
Backing material
PVC film
Color
black
Rating properties
Abrasion resistance
+
Resistance to chemicals
++
Scratch resistance
++
Temperature resistance
+
Suitable for die cutting
Yes
Matt surface finish
Yes
UV-resistance
++
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
