Liner variants:
PV20 brown/blue logo glassine paper (71µm; 82g/m²)
PV20 brown/blue logo glassine paper (71µm; 82g/m²)
tesa® 51972
48µm double sided black filmic tape
Product Features
- Thickness: 48µm
- High adhesion level
- Excellent resistance to demanding environmental conditions
Product description
tesa® 51972 is a double-sided self-adhesive tape consisting of a black PET backing and a tackified acrylic adhesive.
Product details and specifications
Product Features
- Thickness: 48µm
- High adhesion level
- Excellent resistance to demanding environmental conditions
- Excellent handling performance in converting processes
Application Fields
- Mounting of metal or plastic badges and signs
- Fixing of reflection foil to LCD frame
- Splicing of thin plastic films
Product Construction
| Adhesive Type | tackified acrylic |
|---|---|
| Backing material | PET film |
| Color | black |
| Total thickness | 48 µm |
Product Construction
| Adhesive Type | tackified acrylic |
|---|---|
| Backing material | PET film |
| Color | black |
| Total thickness | 48 µm |
Properties / Performance Values
| Elongation at break | 50 % |
|---|---|
| Tensile strength | 20 N/cm |
| Static shear resistance at 23°C | good |
| Softener resistance | good |
| Static shear resistance at 40°C | medium |
| Chemical Resistance | good |
| Temperature resistance short term | 200 °C |
| Tack | medium |
| Temperature resistance long term | 100 °C |
| Humidity resistance | very good |
| Ageing resistance (UV) | very good |
Properties / Performance Values
| Elongation at break | 50 % |
|---|---|
| Tensile strength | 20 N/cm |
| Static shear resistance at 23°C | good |
| Softener resistance | good |
| Static shear resistance at 40°C | medium |
| Chemical Resistance | good |
| Temperature resistance short term | 200 °C |
| Tack | medium |
| Temperature resistance long term | 100 °C |
| Humidity resistance | very good |
| Ageing resistance (UV) | very good |
Adhesion to Values
| Adhesion to ABS (initial) | 5.3 N/cm |
|---|---|
| Adhesion to ABS (after 14 days) | 6.5 N/cm |
| Adhesion to Aluminium (initial) | 5.2 N/cm |
| Adhesion to Aluminium (after 14 days) | 7.7 N/cm |
| Adhesion to PC (initial) | 6.5 N/cm |
| Adhesion to PC (after 14 days) | 8.6 N/cm |
| Adhesion to PE (initial) | 3.1 N/cm |
| Adhesion to PE (after 14 days) | 3.5 N/cm |
| Adhesion to PET (initial) | 5.3 N/cm |
| Adhesion to PET (after 14 days) | 7 N/cm |
| Adhesion to PP (initial) | 3 N/cm |
| Adhesion to PP (after 14 days) | 4.8 N/cm |
| Adhesion to PS (initial) | 5.4 N/cm |
| Adhesion to PS (after 14 days) | 7.1 N/cm |
| Adhesion to PVC (initial) | 5.7 N/cm |
| Adhesion to PVC (after 14 days) | 9.4 N/cm |
| Adhesion to Steel (initial) | 7 N/cm |
| Adhesion to Steel (after 14 days) | 9.6 N/cm |
Adhesion to Values
| Adhesion to ABS (initial) | 5.3 N/cm |
|---|---|
| Adhesion to ABS (after 14 days) | 6.5 N/cm |
| Adhesion to Aluminium (initial) | 5.2 N/cm |
| Adhesion to Aluminium (after 14 days) | 7.7 N/cm |
| Adhesion to PC (initial) | 6.5 N/cm |
| Adhesion to PC (after 14 days) | 8.6 N/cm |
| Adhesion to PE (initial) | 3.1 N/cm |
| Adhesion to PE (after 14 days) | 3.5 N/cm |
| Adhesion to PET (initial) | 5.3 N/cm |
| Adhesion to PET (after 14 days) | 7 N/cm |
| Adhesion to PP (initial) | 3 N/cm |
| Adhesion to PP (after 14 days) | 4.8 N/cm |
| Adhesion to PS (initial) | 5.4 N/cm |
| Adhesion to PS (after 14 days) | 7.1 N/cm |
| Adhesion to PVC (initial) | 5.7 N/cm |
| Adhesion to PVC (after 14 days) | 9.4 N/cm |
| Adhesion to Steel (initial) | 7 N/cm |
| Adhesion to Steel (after 14 days) | 9.6 N/cm |
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
