tesa® 4820

PTFE tape with a silicone adhesive



Product description

tesa® 4820 is a premium single sided PTFE tape with silicone adhesive. This product is a self-adhesive and high performance tape for demanding applications, in which high temperature resistance, very good release properties and abrasion resistance is needed.
Features:
  • Excellent release properties due to PTFE surface and its low surface energy
  • Special silicone adhesive with well-balanced properties: Excellent adhesion level, residue free removable, no oozing at the edges
  • Smooth surface with low friction coefficient
  • Enhanced mechanical stability and abrasion resistance
  • Tensilized material for high tensile strength
  • Excellent temperature resistance
  • Superior resistance against chemicals and solvents

Main applications

  • Belt realization to avoid the just extruded PE edges sticking on the cylinders by laminating tesa® 4820 and tesa® 4830 together
  • Cylinder wrapping on the extrusion coating line next to the hole of the caps
  • High temperature, low friction, anti-stick properties for high end requirements

Technical properties

Elongation at break

105 %

Type of adhesive

silicone

Total thickness

100 µm

Backing material

PTFE film

Adhesion to steel

2.5 N/cm

Color

blue-translucent

Temperature resistance

250 °C

Tensile strength

130 N/cm

Rating properties

Abrasion resistance

++

tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
