tesa® 4820

PTFE tape with a silicone adhesive

Product Features
  • Excellent release properties due to PTFE surface and its low surface energy
  • Special silicone adhesive with well-balanced properties: Excellent adhesion level, residue free removable, no oozing at the edges
  • Smooth surface with low friction coefficient
All product features

Product description

tesa® 4820 is a premium single sided PTFE tape with silicone adhesive. This product is a self-adhesive and high performance tape for demanding applications, in which high temperature resistance, very good release properties and abrasion resistance is needed.

Product Features

  • Excellent release properties due to PTFE surface and its low surface energy
  • Special silicone adhesive with well-balanced properties: Excellent adhesion level, residue free removable, no oozing at the edges
  • Smooth surface with low friction coefficient
  • Enhanced mechanical stability and abrasion resistance
  • Tensilized material for high tensile strength
  • Excellent temperature resistance
  • Superior resistance against chemicals and solvents

Application Fields

  • Belt realization to avoid the just extruded PE edges sticking on the cylinders by laminating tesa® 4820 and tesa® 4830 together
  • Cylinder wrapping on the extrusion coating line next to the hole of the caps
  • High temperature, low friction, anti-stick properties for high end requirements

Product Construction

Backing material PTFE film
Color blue-translucent
Total thickness 100 µm
Type of adhesive silicone

Properties / Performance Values

Temperature resistance 250 °C
Elongation at break 105 %
Tensile strength 130 N/cm
Abrasion resistance very good

Adhesion to Values

Adhesion to Steel 2.5 N/cm
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
