tesa® 4156 PV2

Speciality tape for film mounting


Product Features
  • tesa® 4156 PV2 is light and age resistant and is easily removed without splitting or tearing. It also does not leave adhesive residues.
  • tesa® 4156 PV2 is easily applied as the tape lies flat during positioning and is not prone to edge curling.
  • tesa® 4156 PV2 ensures secure masking with perfect edge definition
All product features
Product description

tesa® 4156 PV2 is a specialty tape designed for film and negative masking. The tape is available as litho-red (colour 57).


Product details and specifications

Product Features

  • tesa® 4156 PV2 is light and age resistant and is easily removed without splitting or tearing. It also does not leave adhesive residues.
  • tesa® 4156 PV2 is easily applied as the tape lies flat during positioning and is not prone to edge curling.
  • tesa® 4156 PV2 ensures secure masking with perfect edge definition
  • tesa® 4156 PV2 is highly transparent to the human eye even without the use of a light table. Parts already masked therefore remain visible thus enabling accurate positioning of the tape.
  • tesa® 4156 PV2 is also suitable for splicing of film.

Application Fields

tesa® 4156 PV2 is a specialty tape designed for film and negative mounting.
Backing material cellophane
Colour litho-red
Total thickness 50 µm
Type of adhesive natural rubber
Adhesion to Steel (initial) 3 N/cm
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
Downloads

Download the files below for more technical details and information on this product.

Get in contact with us!

Contact us

Thank you for your message.

We will contact you as soon as possible.

Something went wrong. Please try again later.

Product comparison

Name of product tesa® 4156 PV2 tesa® 62580 tesa® 7475 PV2 tesa® 65610 Removable (Single-Use) tesa® flameXtinct 45020 Differential tesa® 58332 50µm D/S PET tesa® 58335 150µm D/S PET tesa® 58334 100µm D/S PET tesa® 58374 tesa® 4563 PV3 tesa® 54338PV0
Total thickness
50 µm
1,200 µm
190 µm
50 µm
150 µm
100 µm
100
380 µm
95 µm
Type of adhesive
natural rubber
functional
acrylic
tackified acrylic
FR acrylic
tackified acrylic
tackified acrylic
tackified acrylic
tackified acrylic
natural rubber
modified acrylic
Backing material
cellophane
PET film
PETP
PE foam
PET
PET
PET
PET
PET
Silicone-coated cloth
PET film
Adhesion to Steel (after 14 days)
4 N/cm
8 N/cm
10.5 N/cm
9.7 N/cm
9.5 N/cm
Adhesion to Aluminium (after 14 days)
4 N/cm
7.5 N/cm
9.5 N/cm
Adhesion to PVC (after 14 days)
4 N/cm
Temperature resistance short term duration
80 °C
200 °C
