Additional Info
PV6 = red MOPP liner (80µm)
tesa® flameXtinct 45001
Flame Retardant PE-Foam Tape
Product Features
- Flame retardant
- Wide product portfolio
- Excellent adhesion characteristics on a variety of surfaces
Product description
The tesa® flameXtinct product family comprises a variety of high performance adhesive tape solutions for mounting applications. The tesa® flameXtinct assortment, and thus all contained products are clearly defined by following characteristics:
- Halogen-free
- High performance adhesives
Product details and specifications
Product Features
- Flame retardant
- Wide product portfolio
- Excellent adhesion characteristics on a variety of surfaces
- High conformability and gap filling properties
- Extremely light weight compared to alternative flame retardant bonding opportunities
- Shock absorbing
- Proven flame retardant characteristics according to FAR 25.853(a) app. F part1 and UL 94 HBF - HF1
Application Fields
- Mounting in elevator
- Bonding in aircraft cabin interior
- Assemblies in trains
- Marine applications
- Automotive
Product Construction
| Adhesive Type | FR acrylic |
|---|---|
| Backing material | FR PE foam |
| Color | white |
| Liner Type | plain red |
| Total thickness | 1000 µm |
Product Construction
| Adhesive Type | FR acrylic |
|---|---|
| Backing material | FR PE foam |
| Color | white |
| Liner Type | plain red |
| Total thickness | 1000 µm |
Properties / Performance Values
| Temperature resistance short term | 80 °C |
|---|---|
| Temperature resistance long term | 80 °C |
| Static shear resistance at 40°C | good |
Properties / Performance Values
| Temperature resistance short term | 80 °C |
|---|---|
| Temperature resistance long term | 80 °C |
| Static shear resistance at 40°C | good |
Adhesion to Values
| Adhesion to Aluminium (initial) | 16.6 N/cm |
|---|---|
| Adhesion to Aluminium (after 14 days) | 21.8 N/cm |
| Adhesion to Steel (initial) | 19.2 N/cm |
| Adhesion to Steel (after 14 days) | 22 N/cm |
Adhesion to Values
| Adhesion to Aluminium (initial) | 16.6 N/cm |
|---|---|
| Adhesion to Aluminium (after 14 days) | 21.8 N/cm |
| Adhesion to Steel (initial) | 19.2 N/cm |
| Adhesion to Steel (after 14 days) | 22 N/cm |
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
