tesa® 63305
50µm double sided transparent tape
Product Features
- Thickness: 50µm
- High bonding strength
- Very high push out and shock resistance
Product description
tesa® 63305 is a double-sided mounting tape with a special reworkable adhesive
Product details and specifications
Product Features
- Thickness: 50µm
- High bonding strength
- Very high push out and shock resistance
- High performance on LSE substrates
- Excellent permanent reworkability on various substrates
- After separation the adhesive is reworkable by stretching or peeling
- Easy reworkability even after a long bonding time
Application Fields
- Demanding mounting
- Permanent mounting of components in electronic devices with the option to remove the parts for repairing or recycling
- Temporary mounting prior to mechanical fixation
Product Construction
| Adhesive Type | specialty |
|---|---|
| Backing material | none |
| Color | transparent |
| Liner Type | glassine |
| Total thickness | 50 µm |
Product Construction
| Adhesive Type | specialty |
|---|---|
| Backing material | none |
| Color | transparent |
| Liner Type | glassine |
| Total thickness | 50 µm |
Properties / Performance Values
| Temperature resistance short term | 90 °C |
|---|---|
| Temperature resistance long term | 60 °C |
| Static shear resistance at 40°C | very good |
Properties / Performance Values
| Temperature resistance short term | 90 °C |
|---|---|
| Temperature resistance long term | 60 °C |
| Static shear resistance at 40°C | very good |
Adhesion to Values
| Adhesion to Glass (initial) | 7 N/cm |
|---|---|
| Adhesion to Glass (after 14 days) | 8 N/cm |
| Adhesion to PC (initial) | 7 N/cm |
| Adhesion to PC (after 14 days) | 8 N/cm |
| Adhesion to PE (initial) | 6 N/cm |
| Adhesion to PE (after 14 days) | 7 N/cm |
| Adhesion to Steel (initial) | 7 N/cm |
| Adhesion to Steel (after 14 days) | 8 N/cm |
Adhesion to Values
| Adhesion to Glass (initial) | 7 N/cm |
|---|---|
| Adhesion to Glass (after 14 days) | 8 N/cm |
| Adhesion to PC (initial) | 7 N/cm |
| Adhesion to PC (after 14 days) | 8 N/cm |
| Adhesion to PE (initial) | 6 N/cm |
| Adhesion to PE (after 14 days) | 7 N/cm |
| Adhesion to Steel (initial) | 7 N/cm |
| Adhesion to Steel (after 14 days) | 8 N/cm |
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
Downloads
Download the files below for more technical details and information on this product.
