tesa_ECT_ss-foam_dr_004
Product information

tesa® 60685

500µm single sided gray electrically conductive foam tape



Product description

tesa® 60685 is a gray single sided electrically conductive self adhesive foam tape. It consists of a highly compressible electrically conductive foam backing and an electrically conductive adhesive.

tesa® 60685 features especially:

  • Highly compressible with very low force
  • Excellent recovery property
  • Excellent conformability to surface variations and tolerances
  • Good electrical conductivity over a wide working range in XYZ-direction even at high temperatures and humidity
  • High bonding strength even at harsh environmental conditions
  • Excellent shock absorbing and cushioning properties

Main applications

  • Conductive gap filling
  • EMI shielding and grounding applications
  • Electrostatic discharge applications

Technical properties

Type of adhesive

conductive acrylic

Adhesion to Steel (initial)

6 N/cm

Type of liner

PE-coated paper

Colour of liner

white/blue logo

Release of liner

easy

Contact resistance z-direction (initial)

0.03 Ohm / square inch

Total thickness

500 µm

Thickness of liner

120 µm

Backing material

conductive foam

Surface resistance x-y-direction

0.2 Ohm / square

Adhesion to Steel (after 14 days)

8 N/cm

Color

gray

Temperature resistance short term

200 °C

tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
