Product information

tesa® 4338 PV1

High Adhesion Masking Tape up to 120 °C



Product description

tesa® 4338 PV1 is a green colored smooth masking tape with strong adhesion. It is recommended for transportation sectors such as marine, train, truck and various others where a strong adhesion is required to hold large and heavy masks. The green colored and smooth paper backing provides excellent visibility, high conformability and clean paint edges. The aging resistant natural rubber adhesive has a excellent quick stick, provides outdoor usability for up to seven-days, temperature resistance up to 120 °C / 248 F and clean removal.

Main applications

  • Finger friendly smooth paper backing
  • For multiple drying cycles (up to 3 cycles at 120 °C / 40 min.)
  • Up to 7 days outdoor resistance or 30 days indoor use
  • Residue free removal after cooling down of substrates
  • Excellent paint adherence & adhesion on backing
  • Tear resistant
  • Excellent conformability
tesa-4338-High-Performance-Masking-Grade-043380000000-pr
tesa-4338-High-Performance-Masking-Grade-043380000100-pr
tesa-4338-High-Performance-Masking-Grade-043380000200-pr
tesa-4338-High-Performance-Masking-Grade-043380000300-pr
tesa-4338-High-Performance-Masking-Grade-edge-masking-4-app
tesa-4338-High-Performance-Masking-Grade-043380000400-pr
tesa-4338-High-Performance-Masking-Grade-curve-masking-5-app
tesa-4338-High-Performance-Masking-Grade-mask-fixation-6-app
tesa-4338-High-Performance-Masking-Grade-mask-removal-7-app
tesa-4338-High-Performance-Masking-Grade-paint-edge-8-app
tesa-4338-High-Performance-Masking-Grade-spray-painting-10-app
tesa-4338-High-Performance-Masking-Grade-final-result-12-app

tesa-4338-High-Performance-Masking-Grade-043380000000-pr

tesa-4338-High-Performance-Masking-Grade-043380000100-pr

tesa-4338-High-Performance-Masking-Grade-043380000200-pr

tesa-4338-High-Performance-Masking-Grade-043380000300-pr

tesa-4338-High-Performance-Masking-Grade-edge-masking-4-app

tesa-4338-High-Performance-Masking-Grade-043380000400-pr

tesa-4338-High-Performance-Masking-Grade-curve-masking-5-app

tesa-4338-High-Performance-Masking-Grade-mask-fixation-6-app

tesa-4338-High-Performance-Masking-Grade-mask-removal-7-app

tesa-4338-High-Performance-Masking-Grade-paint-edge-8-app

tesa-4338-High-Performance-Masking-Grade-spray-painting-10-app

tesa-4338-High-Performance-Masking-Grade-final-result-12-app

Technical properties

Elongation at break

13 %

Type of adhesive

natural rubber

Tensile strength

43 N/cm

Total thickness

145 µm

Backing material

slightly-creped paper

Adhesion to steel

4 N/cm

Temperature resistance

120 °C

Rating properties

Conformability

+

Sharp color edge

+

Hand tearability

++

Smooth color edge

+

Paint anchorage

++

Easy to remove

yes

Additional Info

Also as tesa® 4338 PV0 available with standard peel adhesion.

tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
