Product information

tesa® 4317

Fine Crepe Paper Masking Tape for Spray Painting



Product description

tesa® 4317 is a thin and flexible masking tape comprised of a fine crepe paper backing and a natural rubber adhesive. The masking tape is suitable for a wide range of general masking applications without or with subsequent oven-drying up to a temperature of 80°C. tesa® 4317 is also resistant to wet sanding. The natural rubber adhesive provides an excellent adhesion to multiple surfaces, like metal, rubber, glass and plastic. The fine crepe paper backing is flexible and conformable and is easy to tear by hand. Paints and fillers adhere well to the reverse side, preventing any kind of flaking.

Main applications

  • tesa® 4317 is a flexible masking tape used for spray-painting, painting, and varnishing applications
  • The masking tape has excellent holding power on various surfaces
  • The tape is suitable for oven-drying with temperatures of up to 80°C
  • Ideal for lacquering work
  • Good flexibility for curves
  • Can be used on painted metal, rubber, glass and chrome parts
  • The tape is easy to remove and is hand-tearable
tesa-4317-thin-paper-masking-tape-for-paint-spraying-chamois-043170001600-pr
tesa_04317_ap_001_fullsize
tesa-4317-thin-paper-masking-tape-for-paint-spraying-round-11-ap
tesa-4317-thin-paper-masking-tape-for-paint-spraying-round-step1of8-ap
tesa-4317-thin-paper-masking-tape-for-paint-spraying-round-step2of8-ap
tesa-4317-thin-paper-masking-tape-for-paint-spraying-round-step3of8-ap
tesa-4317-thin-paper-masking-tape-for-paint-spraying-round-step4of8-ap
tesa-4317-thin-paper-masking-tape-for-paint-spraying-round-step5of8-ap
tesa-4317-thin-paper-masking-tape-for-paint-spraying-round-step6of8-ap
tesa-4317-thin-paper-masking-tape-for-paint-spraying-round-step7of8-ap
tesa-4317-thin-paper-masking-tape-for-paint-spraying-round-step8of8-ap

tesa-4317-thin-paper-masking-tape-for-paint-spraying-chamois-043170001600-pr

tesa_04317_ap_001_fullsize

tesa-4317-thin-paper-masking-tape-for-paint-spraying-round-11-ap

tesa-4317-thin-paper-masking-tape-for-paint-spraying-round-step1of8-ap

tesa-4317-thin-paper-masking-tape-for-paint-spraying-round-step2of8-ap

tesa-4317-thin-paper-masking-tape-for-paint-spraying-round-step3of8-ap

tesa-4317-thin-paper-masking-tape-for-paint-spraying-round-step4of8-ap

tesa-4317-thin-paper-masking-tape-for-paint-spraying-round-step5of8-ap

tesa-4317-thin-paper-masking-tape-for-paint-spraying-round-step6of8-ap

tesa-4317-thin-paper-masking-tape-for-paint-spraying-round-step7of8-ap

tesa-4317-thin-paper-masking-tape-for-paint-spraying-round-step8of8-ap

Technical properties

Backing material

slightly-creped paper

Total thickness

140 µm

Type of adhesive

natural rubber

Adhesion to steel

3.3 N/cm

Adhesion to rough surfaces

1.2 N/cm

Elongation at break

10 %

Tensile strength

38 N/cm

Temperature resistance

80 °C

Rating properties

Hand tearability

++

Easy to remove

yes

Paint anchorage

++

Sharp colour edge

+

Conformability

+

tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
