tesa ^® 4304

Name: tesa® 4304
Brand: tesa®

High performance paper masking tape up to 163°C/325°F

Product description

tesa ^® 4304 is a brown colored smooth crepe paper masking tape for high demanding paint masking applications.

The natural rubber adhesive system makes tesa ^® 4304 suitable for a broad temperature range from 15°C up to 163°C/325°F.

Benefits:
•   Excellent handling (low unwinding forces & finger friendly)
•   Recommended for multiple drying cycles
•   Covering broad range of drying temperatures and residue free removal – from 15°C to 163°C/325°F
•   Excellent adherence of solvent/water-borne paints/fillers on backside
•   Secure bonding of large area masks without lifting-off

Main applications

Masking during spray painting with oven drying up to 163°C/325°F

tesa-4304-High-Performance-Masking-Tape-up-to-163-celsius-043040000401-pr

tesa-4304-High-Performance-Masking-Tape-up-to-163-celsius-step1of5-ap

tesa-4304-High-Performance-Masking-Tape-up-to-163-celsius-step2of5-ap

tesa-4304-High-Performance-Masking-Tape-up-to-163-celsius-step3of5-ap

tesa-4304-High-Performance-Masking-Tape-up-to-163-celsius-step4of5-ap

tesa-4304-High-Performance-Masking-Tape-up-to-163-celsius-step5of5-ap

tesa -4304-High-Performance-Masking-Tape-up-to-163-celsius-043040000401-pr

tesa -4304-High-Performance-Masking-Tape-up-to-163-celsius-step1of5-ap

tesa -4304-High-Performance-Masking-Tape-up-to-163-celsius-step2of5-ap

tesa -4304-High-Performance-Masking-Tape-up-to-163-celsius-step3of5-ap

tesa -4304-High-Performance-Masking-Tape-up-to-163-celsius-step4of5-ap

tesa -4304-High-Performance-Masking-Tape-up-to-163-celsius-step5of5-ap

Technical properties

Backing material

slightly-creped paper

Total thickness

145 µm

Type of adhesive

natural rubber

Adhesion to steel

4 N/cm

Elongation at break

13 %

Tensile strength

43 N/cm

Temperature resistance

163 °C

Rating properties

Hand tearability

Easy to remove

yes

Paint anchorage

Sharp colour edge

Conformability

tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
