Additional Info
- Standard width: 35 mm
- Standard lengths: 15 m, 10 m
- Standard core diameter: 38 mm
- Additional dimensions on request
- Available as right- & left-hand version (35 mm)
tesa® Spiralsleeve 51036 PV5
PET cloth Sleeve® for superior abrasion protection and enhanced flexibility
Product Features
- High temperature resistance 150°C/3000h
- High flexibility
- Superior abrasion resistance
Product description
tesa® Spiralsleeve 51036 PV5 is a PET cloth Sleeve® coated with an acrylic adhesive for spiral application.
Color: Black
Product details and specifications
Product Features
- High temperature resistance 150°C/3000h
- High flexibility
- Superior abrasion resistance
- Unique adhesive-to-adhesive closure system guarantees secure bonding without additional spot wraps
Application Fields
tesa® Spiralsleeve 51036 PV5 is designed for the engine compartment, providing superior abrasion protection and flexibilty.
It combines the well known spiral application of a tape with the flexibility of a tesa® Sleeve.
It combines the well known spiral application of a tape with the flexibility of a tesa® Sleeve.
Product Construction
| Adhesive Type | advanced acrylic |
|---|---|
| Backing material | PET cloth |
| Total thickness | 530 µm |
Product Construction
| Adhesive Type | advanced acrylic |
|---|---|
| Backing material | PET cloth |
| Total thickness | 530 µm |
Properties / Performance Values
| Temperature resistance min. | -40 °C |
|---|---|
| Abrasion resistance (10mm mandrel, LV312) | Class E |
| Abrasion resistance (5mm mandrel, LV312) | Class D |
| Temperature resistance max. | 150 °C |
| Noise damping (LV312) | Class B |
Properties / Performance Values
| Temperature resistance min. | -40 °C |
|---|---|
| Abrasion resistance (10mm mandrel, LV312) | Class E |
| Abrasion resistance (5mm mandrel, LV312) | Class D |
| Temperature resistance max. | 150 °C |
| Noise damping (LV312) | Class B |
Adhesion to Values
| Adhesion to Steel | 3 N/cm |
|---|
Adhesion to Values
| Adhesion to Steel | 3 N/cm |
|---|
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
Downloads
Download the files below for more technical details and information on this product.
