tesa® Softprint 73922 Secure (SC-M)

Plate Mounting Tape, SC-M, Flex, 500 Soft Foam

Product Features

Secure bond - excellent resistance to edge lifting across a broad temperature range
Reliable mounting also at lower temperatures
Works best in clean and standardized conditions

Product description

tesa® Softprint 73922, a double-sided foam tape, supports with a secure and strong bonding performance to enhance printing process efficiency. The product combines our Secure (SC) plate side adhesive with a medium (M) strong bonding strength towards the sleeves, and is equippend with our embossed PP liner.

Product details and specifications

Product Features

Secure bond - excellent resistance to edge lifting across a broad temperature range
Reliable mounting also at lower temperatures
Works best in clean and standardized conditions

Application Fields

Mounting of 1.14 mm (0.045'') and 1.70 mm (0.067'') flexographic printing plates onto steel /alu /PU and glassine sleeves.

Adhesive Type	tackified acrylic
Backing material	PE foam with film lamination
Liner Type	PP
Total thickness	550 µm

Adhesive Type	tackified acrylic
Backing material	PE foam with film lamination
Liner Type	PP
Total thickness	550 µm

Product design	FLEX
Thickness category	500
Hardness	soft
Color of foam	red

Product design	FLEX
Thickness category	500
Hardness	soft
Color of foam	red

tesa® Softprint Secure is available in two different product designs (Classic or Flex), five different foam hardnesses (X-Soft, Soft, Medium, Medium-Hard, Hard), and with two liner options (embossed PP liner, structured Easy Application (EA) liner) to support a reliable, efficient process with the best print quality outcome.

Flex design equipped with flexible PE reinforcement layer
Foam properties: Long lasting, constant recovery characteristics
Liner: white embossed PP liner

tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.

Downloads

Download the files below for more technical details and information on this product.

Product information_tesa® Softprint 73922_en 55.1 kB

Contact us

Thank you for your message.

We will contact you as soon as possible.

Something went wrong. Please try again later.

Product comparison

Name of product	tesa® Softprint 73922 Secure (SC-M)	tesa® Softprint 73324 TP-X (EA), Medium	tesa® Softprint 73322 TP-X (EA), Soft	tesa® Softprint 73326 TP-X (EA), Medium-Hard	tesa® Softprint 52814 SEC	tesa® Softprint 52015 Steel Master	tesa® Softprint 72228 Sleevemaster	tesa® Softprint 52115 TP	tesa® Softprint 72420 FE	tesa® Softprint 72028 Steelmaster	tesa® Softprint 52060 BigFoam	tesa® Softprint 73126 Steelmaster TP
Total thickness	550 µm	550 µm	550 µm	550 µm	430 µm	430 µm	550 µm	430 µm	550 µm	550 µm		550 µm
Adhesive Type	tackified acrylic	tackified acrylic	tackified acrylic	tackified acrylic	tackified acrylic	tackified acrylic	tackified acrylic	tackified acrylic	tackified acrylic	tackified acrylic	tackified acrylic	tackified acrylic
Backing material	PE foam with film lamination	PE foam with film lamination	PE foam with film lamination	PE foam with film lamination	PE foam with film lamination	PE foam with film lamination	PE foam with film lamination	PE foam with film lamination	PE foam with film lamination	PE foam with film lamination	PE foam	PE foam with film lamination
Thickness category	500	500	500	500	380	380	500	380	500	500	1500	500
Hardness	soft	medium	soft	medium-hard	hard	medium-hard	hard	medium-hard	extra soft	hard	medium	medium-hard
Color of foam	red	purple	red	blue				white
Liner Type	PP	PP	PP	PP	PP	PP	PP	PP	PP	PP	PP	PP
