Product description
Double-sided foam tape
Foam properties
- Low thickness tolerance
- Long lasting, constant recovery characteristics
Adhesive properties
- Medium tack surface characteristics
- Sufficient plate bonding
- Easy plate demounting
- Sufficient tape bonding towards sleeve side
Addtional property
- Structured PP-liner to prevent formation of air pockets when the plate is mounted
Main applications
Mounting of 1,14 mm (0,045'') and 1,70 mm (0,067'') flexographic printing plates onto steel /alu /PU and glassine cylinders
Technical properties
Backing material
PE foam with film lamination
Total thickness
550 µm
Thickness category
500 µm
Type of adhesive
tackified acrylic
Type of liner
PP
Logo colour
grey
Hardness
extra-hard
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
