Additional Info
- Liner: PV 26 = White siliconised PE-coated paper liner
tesa® ACXplus 77108
0.8 mm double-sided acrylic foam tape for mounting automotive exterior attachment parts
Product description
tesa® ACXplus 77108 is a high performance double-sided acrylic foam tape for exterior attachment part mounting. Its outstanding wide temperature range resistance is based on its well-balanced pure acrylic core and tackified adhesive, which assure reliable bonding of the part for the entire life of the vehicle.
Due to the product’s unique formulation, it has the ability to absorb and dissipate the stress on the bonding line and builds up its wetting on the substrate.
Also available in 1.2 mm and 1.5 mm formats.
Main Features
- Excellent shear resistance at elevated temperatures
- Superior wet-out performance for high initial bonding on MSE substrates
- High humidity, gasoline, and UV resistance
- PFAS / PFOS free Product
- Viscoelastic acrylic foam core to compensate for different thermal elongation of bonded parts
- Closed cell acrylic foam core for reliable sealing to prevent water penetration
Product details and specifications
Application Fields
tesa® ACXplus 77108 is suitable for a wide range of exterior mounting applications.
Example applications are the permanent exterior mounting of:
Example applications are the permanent exterior mounting of:
- Body side moldings and decorative trims
- Emblems
- Spoilers
- Antennas
- Pillar appliques
Product Construction
| Adhesive Type | tackified acrylic |
|---|---|
| Backing material | foamed acrylic |
| Color | black |
| Total thickness | 800 µm |
Product Construction
| Adhesive Type | tackified acrylic |
|---|---|
| Backing material | foamed acrylic |
| Color | black |
| Total thickness | 800 µm |
Properties / Performance Values
| Temperature range | -40 to +80 |
|---|---|
| Humidity resistance | very good |
| Ageing resistance (UV) | very good |
Properties / Performance Values
| Temperature range | -40 to +80 |
|---|---|
| Humidity resistance | very good |
| Ageing resistance (UV) | very good |
Adhesion to Values
| Adhesion to ABS (after 3 days) | 25 N/cm |
|---|---|
| Adhesion to Steel (after 3 days) | 29 N/cm |
Adhesion to Values
| Adhesion to ABS (after 3 days) | 25 N/cm |
|---|---|
| Adhesion to Steel (after 3 days) | 29 N/cm |
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
Downloads
Download the files below for more technical details and information on this product.
