Additional Info
- Easy release liner outside of roll
tesa® 61562 Optically Clear Adhesive
25µm moisture control transparent transfer tape
Product Features
- Low WVTR provides moisture control
- Low dielectric constant
- High transmission and low haze
Product description
tesa® 61562 is a highly transparent transfer tape produced under controlled clean room conditions and designed for optically clear lamination which needs additional moisture control
Product details and specifications
Product Features
- Low WVTR provides moisture control
- Low dielectric constant
- High transmission and low haze
- Excellent temperature, humidity and UV resistance
- Excellent ITO compatibility
- Smooth and easy liner removal
- High bonding strength
Application Fields
- Lamination of films to rigid or flexible substrates
- Bonding of sensitive films, displays or touch panel
Product Construction
| Adhesive Type | specialty |
|---|---|
| Backing material | none |
| Color | transparent |
| Color of liner | transparent |
| Liner Type | PET |
| Thickness of easy release liner | 50 µm |
| Thickness of tight release liner | 50 µm |
| Total thickness | 25 µm |
Product Construction
| Adhesive Type | specialty |
|---|---|
| Backing material | none |
| Color | transparent |
| Color of liner | transparent |
| Liner Type | PET |
| Thickness of easy release liner | 50 µm |
| Thickness of tight release liner | 50 µm |
| Total thickness | 25 µm |
Properties / Performance Values
| WVTR (38°C, 90%RH) | 35 g/sqm*d |
|---|---|
| Haze | 0.5 % |
| Refractive index | 1.52 |
| Transmittance (380 - 780nm) > | 99 % |
Properties / Performance Values
| WVTR (38°C, 90%RH) | 35 g/sqm*d |
|---|---|
| Haze | 0.5 % |
| Refractive index | 1.52 |
| Transmittance (380 - 780nm) > | 99 % |
Adhesion to Values
| Adhesion to Glass (initial) | 4.5 N/cm |
|---|---|
| Adhesion to PC (initial) | 4.1 N/cm |
| Adhesion to PET (initial) | 2.9 N/cm |
| Adhesion to PMMA (initial) | 4.4 N/cm |
Adhesion to Values
| Adhesion to Glass (initial) | 4.5 N/cm |
|---|---|
| Adhesion to PC (initial) | 4.1 N/cm |
| Adhesion to PET (initial) | 2.9 N/cm |
| Adhesion to PMMA (initial) | 4.4 N/cm |
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
Downloads
Download the files below for more technical details and information on this product.
