tesa® 68105

High performance acrylic transfer tape

Product description

tesa® 68105 is a transparent transfer tape suitable for demanding lamination applications. The pure acrylic adhesive gives this product an excellent compatibility with printing inks, including conductive inks. The adhesive thickness offers the best compromise between adhesion on filmic polymers, high shear resistance and efficient processability. A moisture resistant liner gives this product good dimensional stability for die cutting processes.

tesa® 68105 features:
  • High shear strength under high temperature conditions
  • Easy repositioning during assembling processes
  • Excellent resistance against plasticisers
  • Low outgassing
  • Ageing resistance

Application Fields

  • Lamination of overlays on touch switches
  • Fastening of printed nameplates and label stock
  • Assembly of all kind of filmic multilayer constructions

Product Construction

Backing material none
Colour of liner transparent, translucent
Thickness of liner 75 µm
Total thickness 50 µm
Type of adhesive pure acrylic
Type of liner PET

Properties / Performance Values

Ageing resistance (UV) very good
Chemical resistance good
Humidity resistance good
Softener resistance very good
Static shear resistance at 40°C very good
Static shear resistance at 70°C very good
Tack medium, good
Temperature resistance long term duration 150 °C
Temperature resistance short term duration 200 °C

Adhesion to Values

Adhesion to ABS (initial) 4.3 N/cm
Adhesion to ABS (after 14 days) 6 N/cm
Adhesion to Aluminium (initial) 3.6 N/cm
Adhesion to Aluminium (after 14 days) 5.5 N/cm
Adhesion to PC (initial) 5 N/cm
Adhesion to PC (after 14 days) 6.6 N/cm
Adhesion to PE (initial) 1.1 N/cm
Adhesion to PE (after 14 days) 1.6 N/cm
Adhesion to PET (initial) 3.5 N/cm
Adhesion to PET (after 14 days) 4.5 N/cm
Adhesion to PP (initial) 2.1 N/cm
Adhesion to PP (after 14 days) 2 N/cm
Adhesion to PS (initial) 4.5 N/cm
Adhesion to PS (after 14 days) 5.5 N/cm
Adhesion to PVC (initial) 4 N/cm
Adhesion to PVC (after 14 days) 6.7 N/cm
Adhesion to Steel (initial) 4.6 N/cm
Adhesion to Steel (after 14 days) 6.7 N/cm
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
