tesa® 66737
1660μm d/s PU foam tape
Product description
tesa® 66737 is a black double-sided tape consisting of a super soft polyurethane foam backing equipped with black acrylic adhesive.
tesa® 66737 features
- Thickness: 1660μm
- Super soft and good gap-filling
- Great light blocking in XYZ direction
- Very good bonding strength
- Excellent shear performance
Product details and specifications
Application Fields
- Mounting TV screen and other large display screen to mantel or plastic frame
- Mounting on curve, uneven and rough surfaces
Product Construction
| Adhesive Type | modified acrylic |
|---|---|
| Backing material | PU foam |
| Color | black |
| Color of liner | transparent |
| Liner Type | PET |
| Thickness of liner | 50 µm |
| Total thickness | 1660 µm |
Product Construction
| Adhesive Type | modified acrylic |
|---|---|
| Backing material | PU foam |
| Color | black |
| Color of liner | transparent |
| Liner Type | PET |
| Thickness of liner | 50 µm |
| Total thickness | 1660 µm |
Adhesion to Values
| Adhesion to Steel (initial) | 6 N/cm |
|---|---|
| Adhesion to Steel (after 3 days) | 8.5 N/cm |
| Adhesion to Steel (covered side, after 3 days) | 9 N/cm |
| Adhesion to Steel (covered side, initial) | 6.5 N/cm |
Adhesion to Values
| Adhesion to Steel (initial) | 6 N/cm |
|---|---|
| Adhesion to Steel (after 3 days) | 8.5 N/cm |
| Adhesion to Steel (covered side, after 3 days) | 9 N/cm |
| Adhesion to Steel (covered side, initial) | 6.5 N/cm |
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
