Additional Info
Peel Adhesion:
- immediate: foam splitting on Steel
- after 14 days: foam splitting on Steel, Aluminium, ABS, PC, PET, PVC
tesa® 62615
1500 µm single sided PE foam tape
Product Features
- Thick foam backing with excellent gap filling properties
- High ultimate adhesion level for a reliable bonding performance
- Soft, conformable foam adapting to structured surfaces
Product description
tesa® 62615 is a single sided PE foam tape for gap filling and cushioning applications.
Product details and specifications
Product Features
- Thick foam backing with excellent gap filling properties
- High ultimate adhesion level for a reliable bonding performance
- Soft, conformable foam adapting to structured surfaces
- Fully outdoor suitable: UV, water and ageing resistant
- Suitable for manual and automatic application processes
- It consists of a highly conformable PE foam backing and a tackified acrylic adhesive.
Application Fields
- Gap filling applicaiton
- Cushioning application
Product Construction
| Adhesive Type | tackified acrylic |
|---|---|
| Backing material | PE foam |
| Color | black |
| Total thickness | 1,500 µm |
Product Construction
| Adhesive Type | tackified acrylic |
|---|---|
| Backing material | PE foam |
| Color | black |
| Total thickness | 1,500 µm |
Properties / Performance Values
| Elongation at break | 190 % |
|---|---|
| Tensile strength | 12 N/cm |
| Static shear resistance at 23°C | good |
| Static shear resistance at 40°C | good |
| Humidity resistance | very good |
| Tack | good |
Properties / Performance Values
| Elongation at break | 190 % |
|---|---|
| Tensile strength | 12 N/cm |
| Static shear resistance at 23°C | good |
| Static shear resistance at 40°C | good |
| Humidity resistance | very good |
| Tack | good |
Adhesion to Values
| Adhesion to ABS (initial) | 8 N/cm |
|---|---|
| Adhesion to ABS (after 14 days) | 12 N/cm |
| Adhesion to Aluminium (initial) | 8 N/cm |
| Adhesion to Aluminium (after 14 days) | 12 N/cm |
| Adhesion to PC (initial) | 8 N/cm |
| Adhesion to PC (after 14 days) | 12 N/cm |
| Adhesion to PE (initial) | 0.9 N/cm |
| Adhesion to PE (after 14 days) | 1.5 N/cm |
| Adhesion to PET (initial) | 8 N/cm |
| Adhesion to PET (after 14 days) | 12 N/cm |
| Adhesion to PP (initial) | 0.9 N/cm |
| Adhesion to PP (after 14 days) | 1.5 N/cm |
| Adhesion to PS (initial) | 8 N/cm |
| Adhesion to PS (after 14 days) | 12 N/cm |
| Adhesion to PVC (initial) | 6 N/cm |
| Adhesion to PVC (after 14 days) | 12 N/cm |
| Adhesion to Steel (initial) | 12 N/cm |
| Adhesion to Steel (after 14 days) | 12 N/cm |
Adhesion to Values
| Adhesion to ABS (initial) | 8 N/cm |
|---|---|
| Adhesion to ABS (after 14 days) | 12 N/cm |
| Adhesion to Aluminium (initial) | 8 N/cm |
| Adhesion to Aluminium (after 14 days) | 12 N/cm |
| Adhesion to PC (initial) | 8 N/cm |
| Adhesion to PC (after 14 days) | 12 N/cm |
| Adhesion to PE (initial) | 0.9 N/cm |
| Adhesion to PE (after 14 days) | 1.5 N/cm |
| Adhesion to PET (initial) | 8 N/cm |
| Adhesion to PET (after 14 days) | 12 N/cm |
| Adhesion to PP (initial) | 0.9 N/cm |
| Adhesion to PP (after 14 days) | 1.5 N/cm |
| Adhesion to PS (initial) | 8 N/cm |
| Adhesion to PS (after 14 days) | 12 N/cm |
| Adhesion to PVC (initial) | 6 N/cm |
| Adhesion to PVC (after 14 days) | 12 N/cm |
| Adhesion to Steel (initial) | 12 N/cm |
| Adhesion to Steel (after 14 days) | 12 N/cm |
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
