tesa® 62615
1500 µm single sided PE foam tape
Product description
tesa® 62615 is a single sided PE foam tape for gap filling and cushioning applications. It consists of a highly conformable PE foam backing and a tackified acrylic adhesive.Product benefits:
- Thick foam backing with excellent gap filling properties
- High ultimate adhesion level for a reliable bonding performance
- Soft, conformable foam adapting to structured surfaces
- Fully outdoor suitable: UV, water and ageing resistant
- Suitable for manual and automatic application processes
Main applications
- Gap filling applicaiton
- Cushioning application
Technical properties
Elongation at break
190 %
Type of adhesive
tackified acrylic
Tensile strength
12 N/cm
Total thickness
1500 µm
Backing material
PE foam
Color
black
Adhesion properties
Adhesion to Steel (initial)
12 N/cm
Adhesion to PE (initial)
0.9 N/cm
Adhesion to PC (after 14 days)
12 N/cm
Adhesion to PS (after 14 days)
12 N/cm
Adhesion to ABS (initial)
8 N/cm
Adhesion to ABS (after 14 days)
12 N/cm
Adhesion to PP (after 14 days)
1.5 N/cm
Adhesion to PET (after 14 days)
12 N/cm
Adhesion to Aluminium (after 14 days)
12 N/cm
Adhesion to PC (initial)
8 N/cm
Adhesion to PVC (initial)
6 N/cm
Adhesion to PE (after 14 days)
1.5 N/cm
Adhesion to PS (initial)
8 N/cm
Adhesion to PET (initial)
8 N/cm
Adhesion to Aluminium (initial)
8 N/cm
Adhesion to PP (initial)
0.9 N/cm
Adhesion to Steel (after 14 days)
12 N/cm
Adhesion to PVC (after 14 days)
12 N/cm
Rating properties
Static shear resistance at 23°C
+
Humidity resistance
++
Tack
+
Ageing resistance (UV)
++
Temperature resistance long term
80 °C
Static shear resistance at 40°C
+
Temperature resistance short term
80 °C
Softener resistance
o
Additional Info
Liner variants:- PV43 white PE-coated paper /blue tesa logo
Peel Adhesion:
- immediate: foam splitting on Steel
- after 14 days: foam splitting on Steel, Aluminium, ABS, PC, PET, PVC
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
