tesa® 6190 Combitape
205µm double sided PET film box sealing tape with integrated tear-tape
Product Features- Implementing closure and opening function in limited space
- Fast liner removal due to fingerlift
- High initial adhesion for fast closure
Product description
tesa® 6190 Combitape is a transparent, double-sided tape consisting of a PET backing and a tackified acrylic adhesive. The double-sided filmic box sealing tape is supplied with fingerlift (extended liner) and integrated tear tape. tesa® 6190 Combitape has been designed for corrugated-board cartons and is recycling friendly according to the INGEDE method. The tackified acrylic adhesive provides reliable bonding performance even at high temperatures and on rough cardboard surfaces.
Product Features
- Implementing closure and opening function in limited space
- Fast liner removal due to fingerlift
- High initial adhesion for fast closure
- Reliable bonding performance even at high temperatures and on rough corrugated-board surfaces
- Recycling friendly according to the INGEDE method
Application Fields
- tesa® 6190 Combitape is especially designed for corrugated-board cartons
- Self-adhesive mail-order boxes
- Closing CD and book cartons
Product Construction
| Backing material | PET film |
| Type of adhesive | tackified acrylic, acrylic, advanced acrylic, modified acrylic |
| Type of liner | MOPP |
| Total thickness | 205 µm |
| Color | transparent, optically clear |
| Color of liner | red, transparent |
| Thickness of liner | 80 µm |
| Weight of liner | 72 g/m² |
Properties / Performance Values
| Elongation at break | 30 % |
| Tensile strength | 130 N/cm |
| Ageing resistance (UV) | very good |
| Chemical resistance | good |
| Humidity resistance | very good |
| Softener resistance | good |
| Static shear resistance at 23°C | good |
| Static shear resistance at 40°C | good |
| Tack | good |
| Temperature resistance long term | 100 °C |
| Temperature resistance min. | -40 °C |
| Temperature resistance short term | 200 °C |
Adhesion to Values
| Adhesion to ABS (initial) | 10.3 N/cm |
| Adhesion to ABS (after 14 days) | 12 N/cm |
| Adhesion to Aluminium (initial) | 9.2 N/cm |
| Adhesion to Aluminium (after 14 days) | 10.6 N/cm |
| Adhesion to PC (initial) | 12.6 N/cm |
| Adhesion to PC (after 14 days) | 14 N/cm |
| Adhesion to PE (initial) | 5.8 N/cm |
| Adhesion to PE (after 14 days) | 6.9 N/cm |
| Adhesion to PET (initial) | 9.2 N/cm |
| Adhesion to PET (after 14 days) | 9.5 N/cm |
| Adhesion to PP (initial) | 6.8 N/cm |
| Adhesion to PP (after 14 days) | 7.9 N/cm |
| Adhesion to PS (initial) | 10.6 N/cm |
| Adhesion to PS (after 14 days) | 12 N/cm |
| Adhesion to PVC (initial) | 8.7 N/cm |
| Adhesion to PVC (after 14 days) | 13 N/cm |
| Adhesion to Steel (initial) | 11.5 N/cm |
| Adhesion to Steel (after 14 days) | 11.8 N/cm |
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
