tesa® 50103
PET - filmic tape for cable mounting in automotive interiors
Product description
tesa® 50103 is a PET filmic tape with an acrylic adhesive for applications in automotive interiors.Features:
- linerless
- suitable for common irregular, rough and critical interior surfaces
- often suitable without any kind of surface pretreatments
- tear resistant
- low and stable unwind force
- can be used with automatic tape dispensers
Main applications
Cable mountingquick and secure fixation of flat and round cables
Additional Info
AF89 = handtearabletesa’s automation and application department provides customized equipment and self-designed application tools to enhance productivity.
Adhesion values to:
PET
PET fleece surface
PET fleece Headliner A
are not part of the product specification
Technical properties
Thickness of tape
90 µm
Elongation at break
65 %
Type of adhesive
acrylic
Tensile strength
45 N/cm
Backing material
PETP
Color
transparent
Adhesion properties
Adhesion to PET fleece surface (initial)
3.4 N/cm
Adhesion to PET fleece Headliner A (after 3 days)
5.9 N/cm
Adhesion to PET fleece surface (after 3 days)
4.1 N/cm
Adhesion to PET fleece Headliner A (initial)
5.8 N/cm
Adhesion to PET (initial)
6 N/cm
Adhesion to PET (after 3 days)
7.2 N/cm
Rating properties
Conformability
o
Static shear resistance
o
Tack
+
Static peel resistance
o
Temperature resistance short term
160 °C
Hand tearability
-
Low VOC
++
Suitable for rough surfaces
++
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
