Product Construction
| Adhesive Type | acrylic |
| Backing material | none |
| Color | transparent |
| Color of liner | transparent |
| Liner Type | PET film |
| Thickness of easy release liner | 75 µm |
| Thickness of tight release liner | 75 µm |
| Total thickness | 200 µm |
tesa® 7108 Optical Clear Adhesive
200μm pressure sensitive optically clear tape with mura resistant feature
Product Features
- Pressure sensitive design
- Good gap filling property
- Laminate glass with rigid display like LCD without Mura/optical distortion
Product description
tesa® 7108 is a highly transparent transfer tape produced for optically clear lamination on rigid or flexible substrates. It is developed for medium to big size display with glass cover lamination to LCD panel. It is an optically clear adhesive tape with pressure sensitive design.
Product details and specifications
Product Features
- Pressure sensitive design
- Good gap filling property
- Laminate glass with rigid display like LCD without Mura/optical distortion
- Superior temperature, humidity and UV resistance
Application Fields
optically clear lamination on rigid or flexible substrates
Product Construction
| Adhesive Type | acrylic |
| Backing material | none |
| Color | transparent |
| Color of liner | transparent |
| Liner Type | PET film |
| Thickness of easy release liner | 75 µm |
| Thickness of tight release liner | 75 µm |
| Total thickness | 200 µm |
Properties / Performance Values
| Ageing resistance (UV) | very good |
| Refractive index | 1.48 |
| Temperature resistance long term | 105 °C |
| Haze | 0.1 % |
| Humidity resistance | very good |
| Transmittance (380 - 780nm) > | 99 % |
Properties / Performance Values
| Ageing resistance (UV) | very good |
| Refractive index | 1.48 |
| Temperature resistance long term | 105 °C |
| Haze | 0.1 % |
| Humidity resistance | very good |
| Transmittance (380 - 780nm) > | 99 % |
Adhesion to Values
| Adhesion to Glass (initial) | 8.2 N/cm |
| Adhesion to PC (initial) | 8.4 N/cm |
| Adhesion to PET (initial) | 7.5 N/cm |
| Adhesion to Polarizer (initial) | 7.7 N/cm |
Adhesion to Values
| Adhesion to Glass (initial) | 8.2 N/cm |
| Adhesion to PC (initial) | 8.4 N/cm |
| Adhesion to PET (initial) | 7.5 N/cm |
| Adhesion to Polarizer (initial) | 7.7 N/cm |
Additional Info
Easy liner outside in logroll
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
