tesa® 5010 Advanced Masking Tape
Advanced fine crepe paper masking tape with temperature resistance of 212°F (100°C)
Product Features
- The bright yellow crepe paper backing ensures excellent visibility and good conformability. It is durable and robust for high tear resistance upon removal.
- The natural rubber adhesive system features good adhesion to multiple surfaces as well as a good tack.
- The advanced masking tape offers high temperature resistance up to 212°F (100°C) for 60 minutes or 230°F (110°C) for 30 min and clean removal.
Product description
tesa® 5010 is a performance masking tape featuring a fine and durable crepe paper backing in bright yellow, complemented by a natural rubber adhesive. The adhesive features good adhesive power to various surfaces, as well as challenging surfaces such as painted metal or rubber. This performance masking tape is well-suited for performance spray painting as well as various general-purpose applications including holding, sealing, fixing, and color coding. It is hand-tearable, easy to remove and resistant to wet sanding. Paints and fillers adhere well to the backing. It offers temperature resistance up to 212°F (100°C) for 1 hr, making it ideal for subsequent oven drying processes. It comes with strong tear resistance for clean one-piece-removal.
Product details and specifications
Product Features
- The bright yellow crepe paper backing ensures excellent visibility and good conformability. It is durable and robust for high tear resistance upon removal.
- The natural rubber adhesive system features good adhesion to multiple surfaces as well as a good tack.
- The advanced masking tape offers high temperature resistance up to 212°F (100°C) for 60 minutes or 230°F (110°C) for 30 min and clean removal.
- Suitable for different paints and fillers.
Application Fields
- tesa® 5010 is suitable for performance spray painting and all kind of multi-purpose masking applications.
- It provides temperature resistance up to 212°F (100°C) and is suitable for subsequent oven drying.
- Finger friendly, smooth and hand-tearable paper backing with excellent conformability.
- High tear resistance and residue free removal after cooling down of substrates
Product Construction
| Adhesive Type | natural rubber |
|---|---|
| Backing material | slightly-creped paper |
| Total thickness |
6.5 mils
165 µm |
Product Construction
| Adhesive Type | natural rubber |
|---|---|
| Backing material | slightly-creped paper |
| Total thickness |
6.5 mils
165 µm |
Properties / Performance Values
| Elongation at break | 10 % |
|---|---|
| Tensile strength |
22.84 lbs/in
40 N/cm |
| Hand tearability | very good |
| Paint anchorage | very good |
| Easy to remove | yes |
| Solvent free | yes |
| Temperature resistance (60 min) |
212 °F
100 °C |
| Sharp color edge | yes |
| Temperature resistance (30 min) |
230 °F
110 °C |
Properties / Performance Values
| Elongation at break | 10 % |
|---|---|
| Tensile strength |
22.84 lbs/in
40 N/cm |
| Hand tearability | very good |
| Paint anchorage | very good |
| Easy to remove | yes |
| Solvent free | yes |
| Temperature resistance (60 min) |
212 °F
100 °C |
| Sharp color edge | yes |
| Temperature resistance (30 min) |
230 °F
110 °C |
Adhesion to Values
| Adhesion to Steel |
2.06 lbs/in
3.6 N/cm |
|---|
Adhesion to Values
| Adhesion to Steel |
2.06 lbs/in
3.6 N/cm |
|---|
Download the files below for more technical details and information on this product.
