tesa® 68618
150µm d/s translucent non-woven tape
Product description
tesa® 68618 is a translucent, double-sided self-adhesive tape consisting of a non-woven backing and a tackified acrylic adhesive.
tesa® 68618 features specially:
- High bonding strength on various kinds of foam, plastic and metal surfaces.
- Good temperature resistance
- Good converting properties
Product details and specifications
Application Fields
- General purpose mounting application
- Lamination of foam and felt
Product Construction
| Backing material | non-woven |
|---|
Product Construction
| Backing material | non-woven |
|---|
Properties / Performance Values
| Tack | very good |
|---|---|
| Static shear resistance at 23°C | good |
Properties / Performance Values
| Tack | very good |
|---|---|
| Static shear resistance at 23°C | good |
Adhesion to Values
| Adhesion to ABS (initial) |
3.71 lbs/in
6.5 N/cm |
|---|---|
| Adhesion to ABS (after 14 days) |
5.71 lbs/in
10 N/cm |
| Adhesion to Aluminium (initial) |
3.31 lbs/in
5.8 N/cm |
| Adhesion to Aluminium (after 14 days) |
5.94 lbs/in
10.4 N/cm |
| Adhesion to PC (initial) |
5.02 lbs/in
8.8 N/cm |
| Adhesion to PC (after 14 days) |
5.2 lbs/in
9.1 N/cm |
| Adhesion to PET (initial) |
3.25 lbs/in
5.7 N/cm |
| Adhesion to PET (after 14 days) |
4.17 lbs/in
7.3 N/cm |
| Adhesion to PMMA (initial) |
5.54 lbs/in
9.7 N/cm |
| Adhesion to PMMA (after 14 days) |
5.77 lbs/in
10.1 N/cm |
| Adhesion to PP (initial) |
2.46 lbs/in
4.3 N/cm |
| Adhesion to PP (after 14 days) |
2.68 lbs/in
4.7 N/cm |
| Adhesion to PS (initial) |
4.4 lbs/in
7.7 N/cm |
| Adhesion to PS (after 14 days) |
6.62 lbs/in
11.6 N/cm |
| Adhesion to PVC (initial) |
3.08 lbs/in
5.4 N/cm |
| Adhesion to PVC (after 14 days) |
6.05 lbs/in
10.6 N/cm |
| Adhesion to Steel (initial) |
5.14 lbs/in
9 N/cm |
| Adhesion to Steel (after 14 days) |
6.28 lbs/in
11 N/cm |
Adhesion to Values
| Adhesion to ABS (initial) |
3.71 lbs/in
6.5 N/cm |
|---|---|
| Adhesion to ABS (after 14 days) |
5.71 lbs/in
10 N/cm |
| Adhesion to Aluminium (initial) |
3.31 lbs/in
5.8 N/cm |
| Adhesion to Aluminium (after 14 days) |
5.94 lbs/in
10.4 N/cm |
| Adhesion to PC (initial) |
5.02 lbs/in
8.8 N/cm |
| Adhesion to PC (after 14 days) |
5.2 lbs/in
9.1 N/cm |
| Adhesion to PET (initial) |
3.25 lbs/in
5.7 N/cm |
| Adhesion to PET (after 14 days) |
4.17 lbs/in
7.3 N/cm |
| Adhesion to PMMA (initial) |
5.54 lbs/in
9.7 N/cm |
| Adhesion to PMMA (after 14 days) |
5.77 lbs/in
10.1 N/cm |
| Adhesion to PP (initial) |
2.46 lbs/in
4.3 N/cm |
| Adhesion to PP (after 14 days) |
2.68 lbs/in
4.7 N/cm |
| Adhesion to PS (initial) |
4.4 lbs/in
7.7 N/cm |
| Adhesion to PS (after 14 days) |
6.62 lbs/in
11.6 N/cm |
| Adhesion to PVC (initial) |
3.08 lbs/in
5.4 N/cm |
| Adhesion to PVC (after 14 days) |
6.05 lbs/in
10.6 N/cm |
| Adhesion to Steel (initial) |
5.14 lbs/in
9 N/cm |
| Adhesion to Steel (after 14 days) |
6.28 lbs/in
11 N/cm |
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
