tesa® 58351
tesa® 58351 is a 73 μm/2.9 mils single-sided transparent PET filmic tape.
Product description
The tackified acrylic adhesive gives this product a very good peel strength and outstanding anti-repulsion property. The 23um/.90 mils transparent PET filmic backing offers excellent electrical insulation property. The glassine liner ensures it can be easily released without adhesive residue. It can meet the strict automotive environmental and long-term durability requirement.
Product details and specifications
Application Fields
- Electrical insulation with anti-repulsion property
| Adhesive Type | tackified acrylic |
|---|---|
| Backing material | PET |
| Color of liner | white/red logo |
| Liner Type | glassine |
| Thickness of liner |
2.8 mils
71 µm |
| Total thickness | 73 |
| Weight of liner |
98.14 lbs/in²
69 g/m² |
| Dielectric breakdown voltage | 6,500 V |
|---|---|
| Breakdown voltage | 6.5 KV |
| Humidity resistance | very good |
| Adhesion to Aluminium (initial) |
2.57 lbs/in
4.5 N/cm |
|---|---|
| Adhesion to Aluminium (after 14 days) |
3.6 lbs/in
6.3 N/cm |
| Adhesion to PC (initial) |
1.88 lbs/in
3.3 N/cm |
| Adhesion to PC (after 14 days) |
3.43 lbs/in
6 N/cm |
| Adhesion to Steel (initial) |
2.86 lbs/in
5 N/cm |
| Adhesion to Steel (after 14 days) |
4.51 lbs/in
7.9 N/cm |
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
