tesa® 66022 low VOC

220µm reinforced water based acrylic adhesive layer with PET scrim for mounting in automotive interiors

Product description

tesa® 66022 is a conformable transparent adhesive layer of water based acrylic reinforced with a PET scrim mesh.

Features:

¹ very low total VOC values and no critical substances detectable

¹ high initial tack and peel adhesion

¹ high conformable design following 3D shapes

¹ provides excellent conformability and stability

¹ provides excellent initial adhesion to a wide variety of interior substrates

¹ suitable for the bonding to nonpolar plastics, foams, felts and fabrics

¹ suitable for a certain gap filling due to thick adhesive layer

¹ reliable adhesion performance for the whole vehicle life time

¹ the scrim provides a reinforcement of flexible substrates for improving converting efficiency and handling

Product details and specifications

Application Fields

immediate secure fixation of light, stiff, rigid, rough parts in vertical and horizontal position
e.g. energy absorber mounting (HIC, crash pad ...)

mounting of plastics as well LSE plastics

¹ with difficult wet-out

¹ permanent low load
Lamination or mounting of critical, soft, light and smooth surfaces / sheets

¹ immediate and secure bending around the edge

Backing material	none
Color	transparent
Colour of liner	brown/blue logo
Thickness of liner	71 µm
Thickness of tape	220 µm
Type of adhesive	water-based acrylic
Type of liner	glassine

Fogging	very good
Suitable for rough surfaces	very good
Temperature resistance max.	200 °C
Low VOC	very good
Suitable for die cutting	yes
Temperature resistance min.	-40 °C
Tack	very good

Adhesion to ABS (initial)	17 N/cm
Adhesion to ABS (after 3 days)	18 N/cm
Adhesion to PC (initial)	19.1 N/cm
Adhesion to PC (after 3 days)	19.4 N/cm
Adhesion to PE (initial)	9.2 N/cm
Adhesion to PE (after 3 days)	9 N/cm
Adhesion to PET (initial)	16.2 N/cm
Adhesion to PET (after 3 days)	18.1 N/cm
Adhesion to PET fleece Headliner A (after 3 days)	8 N/cm
Adhesion to PET fleece Headliner A (initial)	6 N/cm
Adhesion to PP (initial)	14 N/cm
Adhesion to PP (after 3 days)	16 N/cm
Adhesion to PS (initial)	17.7 N/cm
Adhesion to PS (after 3 days)	18.2 N/cm
Adhesion to PVC (initial)	12 N/cm
Adhesion to PVC (after 3 days)	19.3 N/cm
Adhesion to Steel (initial)	12.3 N/cm
Adhesion to Steel (after 3 days)	17.3 N/cm

Is designed to fulfill the low VOC (Volatile Organic Compounds) automotive requirements set forth by the Japanese Ministry of Health, Labor and Welfare (MHLW) and the Japanese Automobile Manufacturers Association (JAMA) limit of concentrations of 13 toxic chemistries. Acc. Toyota TSK0508G our assortment is conform Japanese automotive requirements

Adhesion vaules to:
PVC
PP
ABS
PC
PET
PS
PE
Are not part of the product specification

PV20 brown glassine liner / blue tesa logo
other liner version possible - on request

tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.

Downloads

Download the files below for more technical details and information on this product.

Product information_tesa® 66022_en-AU 1.4 MB
