tesa® 62580

Hydrophilic film for IVD products


Product description

tesa® 62580 is a transparent PET film functionalized on one side with a non-adhesive hydrophilic coating.

tesa® 62580 features:

1 Fast and reliable fluid flow

1 Proven compatibility with many enzymes

1 Excellent aging stability

1 Reliable bonding of the hydrophilic side to tesa spacer tapes

1 Proven performance and integrity of multi-layers with tesa spacer tapes after aging


Product details and specifications

Application Fields

Securing fluid flow in capillary cell in-vitro diagnostic applications.
Backing material PET film
Color transparent
Thickness of tape 100 µm
Type of adhesive functional
Contact Angle 20 °
Wetting Index 36
Storage and handling instructions:

Shelf life: 48 months from date of coating.
Avoid contact with water, material is sensitive against hunidity. Protect against mechanical impacts.

tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
Downloads

Download the files below for more technical details and information on this product.

Get in contact with us!

Contact us

Thank you for your message.

We will contact you as soon as possible.

Something went wrong. Please try again later.

Product comparison

Name of product tesa® 62580 tesa® 62588 tesa® 4156 PV1 tesa® 64802 tesa® 64701 tesa® 64801 tesa® 64803 tesa® 60402 tesa® Printer's Friend 4863 PV3 tesa® 4101 PV2 NOPI® 64110 hand
Type of adhesive
functional
functional
natural rubber
acrylic
acrylic
acrylic
acrylic
acrylic
natural rubber
natural & synthetic rubber
natural rubber
Backing material
PET film
PET film
cellophane
PVC foam
PVC foam
PVC foam
PVC foam
PVC foam
Silicone-coated cloth
hydrate cellulose
PVC film
Total thickness
50 µm
1.6 mm
1.6 mm
1.2 mm
3,200 µm
1,600 µm
620 µm
51 µm
49 µm
Adhesion to Steel (after 14 days)
8 N/cm
8 N/cm
8 N/cm
8 N/cm
Temperature resistance short term
105 °C
105 °C
105 °C
105 °C
