tesa® 51970

Transparent double-sided filmic tape

Product description

tesa® 51970 is a transparent, double sided tape consisting of a PP film backing and a tackified adhesive. tesa® 51970 features an excellent combination of high tack and adhesive strength. It bonds securely even on critical materials such as PP, PE and rough surfaces. The mounting tape's good temperature resistance, as well as UV and humidity resistance make it ideal for outdoor use. The tape can withstand chemicals and softeners. tesa® 51970 is frequently used for industrial mounting applications, for instance, the mounting of plastic or decorative materials.

Product details and specifications

Application Fields

tesa® 51970 is a highly adhesive mounting tape for various industrial uses
The optimal balance of adhesion properties makes tesa® 51970 ideal for various applications in the blinds industry, such as roller blind core starting and laminating hard to adhere fabrics and meshes
The tape can be used for mounting plastic and wooden trims
Suitable for mounting decorative materials and displays
tesa® 51970 is used for mounting transparent signs and scales

Backing material	PP film
Color	transparent
Total thickness	220 µm
Type of adhesive	tackified acrylic

Backing material	PP film
Color	transparent
Total thickness	220 µm
Type of adhesive	tackified acrylic

Elongation at break	150 %
Tensile strength	50 N/cm
Tack	very good
Softener resistance	good
Static shear resistance at 40°C	good
Humidity resistance	very good
Chemical resistance	good
Temperature resistance long term	80 °C
Ageing resistance (UV)	good
Temperature resistance min.	-40 °C
Temperature resistance short term	130 °C
Static shear resistance at 23°C	good

Elongation at break	150 %
Tensile strength	50 N/cm
Tack	very good
Softener resistance	good
Static shear resistance at 40°C	good
Humidity resistance	very good
Chemical resistance	good
Temperature resistance long term	80 °C
Ageing resistance (UV)	good
Temperature resistance min.	-40 °C
Temperature resistance short term	130 °C
Static shear resistance at 23°C	good

Adhesion to ABS (initial)	12.5 N/cm
Adhesion to ABS (after 14 days)	14.5 N/cm
Adhesion to Aluminium (initial)	11.5 N/cm
Adhesion to Aluminium (after 14 days)	12.5 N/cm
Adhesion to PC (initial)	15 N/cm
Adhesion to PC (after 14 days)	16.5 N/cm
Adhesion to PE (initial)	7 N/cm
Adhesion to PE (after 14 days)	8 N/cm
Adhesion to PET (initial)	11 N/cm
Adhesion to PET (after 14 days)	11.5 N/cm
Adhesion to PP (initial)	8.5 N/cm
Adhesion to PP (after 14 days)	10 N/cm
Adhesion to PS (initial)	13 N/cm
Adhesion to PS (after 14 days)	14.5 N/cm
Adhesion to PVC (initial)	11.5 N/cm
Adhesion to PVC (after 14 days)	17.5 N/cm
Adhesion to Steel (initial)	13 N/cm
Adhesion to Steel (after 14 days)	13.5 N/cm

Adhesion to ABS (initial)	12.5 N/cm
Adhesion to ABS (after 14 days)	14.5 N/cm
Adhesion to Aluminium (initial)	11.5 N/cm
Adhesion to Aluminium (after 14 days)	12.5 N/cm
Adhesion to PC (initial)	15 N/cm
Adhesion to PC (after 14 days)	16.5 N/cm
Adhesion to PE (initial)	7 N/cm
Adhesion to PE (after 14 days)	8 N/cm
Adhesion to PET (initial)	11 N/cm
Adhesion to PET (after 14 days)	11.5 N/cm
Adhesion to PP (initial)	8.5 N/cm
Adhesion to PP (after 14 days)	10 N/cm
Adhesion to PS (initial)	13 N/cm
Adhesion to PS (after 14 days)	14.5 N/cm
Adhesion to PVC (initial)	11.5 N/cm
Adhesion to PVC (after 14 days)	17.5 N/cm
Adhesion to Steel (initial)	13 N/cm
Adhesion to Steel (after 14 days)	13.5 N/cm

Liner variants:
PV0 brown glassine paper (65 µm)
PV1 white glassine paper (84 µm)
PV2 white embossed PP (85 µm)
PV6 red MOPP-film (80 µm)

A fingerlift version (extended liner), tesa® 61970, is also available.

tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.

Downloads

Download the files below for more technical details and information on this product.

Safety data sheet_tesa® 51970_en-AU_v13 130.8 kB Product information_tesa® 51970_en-AU 104.9 kB
