tesa® 51206

Special sliding PE-UHMW tape for anti-squeak prevention and abrasion protection


Product description

tesa® 51206 is an ageing and abrasion resistant high density PE tape with very good adhesive power.

Features:

  • Translucency assists the application in the visible area

  • Self-lubricating tape with very good sliding properties reduces wear and friction

  • High energy absorption capacity even at high stress levels


Product details and specifications

Application Fields

tesa® 51206 is especially designed for interior anti-squeak and abrasion protection at the assembly line to ensure a reliable:
  • Masking of sharp-edged sheet-metal components

  • Sliding of delicate components

  • Prevention of noise and wear, e.g from trim parts

  • Protection of harnesses in high friction areas
Backing material PE
Color translucent
Total thickness 114 µm
Type of adhesive pure acrylic
Type of liner white
Elongation at break 300 %
Tensile strength 43 N/cm
Abrasion resistance very good
Adhesion to steel 4.3 N/cm
The material can be supplied as die cuts in roll or sheets individually to customer specific dimensions under tesa® 54206
tesa’s automation and application solution department provides customized equipment and self-designed application tools to enhance productivity.
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
Downloads

Download the files below for more technical details and information on this product.

Get in contact with us!

Contact us

Thank you for your message.

We will contact you as soon as possible.

Something went wrong. Please try again later.

Product comparison

Name of product tesa® 51206 tesa® 54994 tesa® 54994 tesa® 54994 DC NOPI® 64110 hand tesa® 4137 tesa® 51485 tesa® 67330 tesa® 60804 tesa® 4646 tesa® 4089
Total thickness
114 µm
360 µm
187
49 µm
50 µm
115 µm
30 µm
150 µm
180 µm
46 µm
Type of adhesive
pure acrylic
acrylic
acrylic
acrylic
natural rubber
acrylic
acrylic
acrylic
natural rubber
Backing material
PE
PU film
PU film
PU film
PVC film
PET film
PVC film
Polyimide
PVC film
PE film
PP film
