tesa® 51193

Splittable repulpable d/s tape for core starting

Product description

tesa® 51193 is a repulpable double-sided tape. It consists of a splittable paper backing and modified water soluble acrylic adhesive. The liner is made of repulpable paper.

The following features are provided:

Special splittable backing leaves no open adhesive residues
Splitting force especially adjusted to high grammage paper and board
Very low deviation of the splitting force
Very good adhesion even on rough surfaces
High initial tack
Fully repulpable (pH3 –pH9)

Colour: Blue

Product details and specifications

Application Fields

tesa® 51193 is designed for core starting and end tabbing applications in the paper and board industry. It is especially suitable for high grammage paper grades and board.

Core starting: also compatible with automatic dispensers
End tabbing: the splittable backing allows (semi-) automatic roll opening

Backing material	Splittable paper
Total thickness	170 µm
Type of adhesive	repulpable tackified acrylic
Type of liner	repulpable siliconised paper

Shelf life time (packed) < 25°C	12 months
Tack	very good
Static shear resistance	good

tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.

Downloads

Download the files below for more technical details and information on this product.

Product information_tesa® 51193_en-AU 533.2 kB

Contact us

Thank you for your message.

We will contact you as soon as possible.

Something went wrong. Please try again later.

Name of product	tesa® 51193	tesa® CaRes 51913 PV11	tesa® CaRes 51912 PV11	tesa® 51446	tesa® 51190	tesa® 7009	tesa® 51915	tesa® 4441	tesa® 61914	tesa® CaRes 51455 PV11	tesa® 51191
Total thickness	170 µm	65 µm	90 µm	105 µm	130 µm	285 µm	50 µm	140 µm	75 µm	80 µm	130 µm
Type of adhesive	repulpable tackified acrylic	repulpable tackified acrylic	repulpable tackified acrylic	repulpable tackified acrylic	repulpable tackified acrylic	tackified acrylic	repulpable tackified acrylic	repulpable tackified acrylic	modified acrylic	repulpable tackified acrylic	modified acrylic
Backing material	Splittable paper	non-woven	non-woven	flat paper	Splittable paper	non-woven	none	slightly-creped paper	non-woven	flat paper	Splittable paper
Type of liner	repulpable siliconised paper	repulpable siliconised paper	repulpable siliconised paper	none	PET film		repulpable siliconised paper	none	bi-siliconised paper	repulpable siliconised paper	PET film
Type of liner	type: repulpable siliconised paper	type: repulpable siliconised paper	type: repulpable siliconised paper	type: none	type: PET film		type: repulpable siliconised paper	type: none	type: bi-siliconised paper	type: repulpable siliconised paper	type: PET film
Color		blue	blue	blue	blue	translucent	blue		blue	blue
Thickness of tape					130 µm			140 µm	75 µm
