Product information

tesa® 6056

Semi-automatic bench dispenser



Product description

tesa® 6056 is a bench dispenser with pre-set length control and an electromagnetic cross-cutter. It is universally applicable for nearly all kinds of tesa® self-adhesive tapes up to 50 mm wide, particularly cloth and paper tapes. Even difficult-to-cut materials are cut perfectly due to the electromagnetic triggered transverse blade, which ensures a smooth, clean cut.

Main applications

The desired strip length is set on the measuring scale on the left-hand side of the dispenser in a range from 30 to 150 mm. The tesa® tape is unrolled by hand until the measuring roller prevents further tape to be dispensed. By pulling the tape gently downwards, the electromagnetic cross cutter is trigged via a microswitch. The desired strip is automatically cut for use. A single movement of the hand is, therefore, sufficient for unrolling, cutting and removing a tesa® strip of predetermined length. For strips longer than 150 mm, the measuring roller is switched to continuous operation. The tesa® automatic dispenser 6056 is equipped with a control unit to adjust the impact force of the electromagnetic cutter. Set a lower impact force for tapes which are easy to cut, such as filmic tapes of smaller widths, to minimize impact noise and dispenser strain.

tesa_06056_pr_001_fullsize
tesa_06056_ap_001_fullsize

Technical properties

Core diameter

3 inch

Type of tape

single-sided

Application purpose

multifunctional

Length

13.38 inch

Width

5.90 inch

Height

5.23 inch

Mode of drive

automatic

Weight

5500 g

Max. roll diameter

7.08 inch

Type of applicator

table

Max. roll width

1.96 inch

Length presetting up to

1.18 inch

Connections

230 V / 50 Hz

Power supply

10 watt

tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
