tesa® 51608 PV6
Double layer PET fleece sleeve for enhanced harness flexibility in the automotive passenger compartment
Product Features
- High flexibility
- Noise damping
- Easy and efficient lengthwise application
Product description
tesa® 51608 PV6 is a double layer PET fleece wire harness sleeve with a rubber-based adhesive. It combines good noise damping and abrasion resistance features with high flexibility.
tesa® 51608 PV6 is specifically designed for easy and efficient lengthwise application. Customized length-specific perforation for fast and clean tearing is available on request.
Product details and specifications
Product Features
- High flexibility
- Noise damping
- Easy and efficient lengthwise application
- Adhesive-to-adhesive closure system
- Secure bonding without additional spot wraps
- Strong adhesion
- Ageing-resistant
- Flexible and smooth
Application Fields
tesa® 51608 PV6 has been developed for bundling passenger compartment wire harness areas subject to high requirements for both noise damping and harness flexibility.
| Backing material | PET fleece |
|---|---|
| Total thickness | 560 µm |
| Type of adhesive | rubber based |
| Noise damping (LV312) | Class D |
|---|---|
| Temperature resistance max. | 105 °C |
| Abrasion resistance (5mm mandrel, LV312) | Class B |
| Temperature resistance min. | -40 °C |
| Abrasion resistance (10mm mandrel, LV312) | Class B |
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
