Flag-resistant PET cloth tape for high abrasion protection of automotive harnesses
Product Features
High abrasion resistance
High temperature resistance
Flag-resistant
All product featuresProduct description
tesa® 51036 is a flag-resistant PET cloth wire harness tape with a solvent-free, advanced acrylic adhesive. With the new adhesive formula, tesa® 51036 is highly resistant to flagging and ensures secure closure. tesa® 51036 provides excellent abrasion protection of automotive harnesses and withstands high temperatures and demanding environmental conditions.
Its acrylic adhesive is compatible with halogen-free cable jacketing materials (PE/PP) and guarantees enhanced durability.
Product details and specifications
Product Features
High abrasion resistance
High temperature resistance
Flag-resistant
Excellent cable compatibility
Resistant to aging
Can withstand environmental influences
Can be used for manual and automatic application
Flame-retardant
Halogen-free
Tear-resistant
Constant unwind force
Flexible and smooth
Available in black and orange
Application Fields
tesa® 51036 has been specially designed for bundling and wire protection against abrasion. The main application field is the engine compartment of a car, with demanding temperature-related and environmental conditions.
Product Construction
Backing material
PET cloth
Total thickness
260 µm
Type of adhesive
advanced acrylic
Product Construction
Backing material
PET cloth
Total thickness
260 µm
Type of adhesive
advanced acrylic
Properties / Performance Values
Elongation at break
40 %
Tensile strength
275 N/cm
Unwind force (roll width > 9mm)
11 N/roll (30 m/min)
Temperature resistance min.
-40 °C
Abrasion resistance (5mm mandrel, LV312)
Class D
Temperature resistance max.
150 °C
Noise damping (LV312)
Class A
Unwind force (roll width ≤ 9mm)
11 N/roll (30 m/min)
Abrasion resistance (10mm mandrel, LV312)
Class D
Properties / Performance Values
Elongation at break
40 %
Tensile strength
275 N/cm
Unwind force (roll width > 9mm)
11 N/roll (30 m/min)
Temperature resistance min.
-40 °C
Abrasion resistance (5mm mandrel, LV312)
Class D
Temperature resistance max.
150 °C
Noise damping (LV312)
Class A
Unwind force (roll width ≤ 9mm)
11 N/roll (30 m/min)
Abrasion resistance (10mm mandrel, LV312)
Class D
Adhesion to Values
Adhesion to steel
5 N/cm
Adhesion to Values
Adhesion to steel
5 N/cm
Additional Info
Standard widths: 9, 19, 25, 32 mm
Standard lengths: 25 m
Most combinations of width and length are possible
Further dimensions are available upon request
Standard core diameter: 38 mm
Applicable for red ring assembly aid
Minimum temperature while application: 15°C
Elongation at break of 51036 orange: 45%
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
