tesa® 54485 Fireman Access

Allows fireman easy access to extinguish batteries

Product Features

Opening at high temperatures allowing fireman to flood the battery without additional equipment
Fire and heat proof-ness of battery holes > 5 minutes at 500 °C (open flame)
Reliable corrosion protection and sealing against water ingress

All product features

Product description

tesa® 54485 Fireman Access is a fire-, heat- and puncture resistant multi-layer product, comprising of a glass fiber laminated aluminum layer and strong PET layer with a thick acrylic adhesive sealer.

Product details and specifications

Product Features

Opening at high temperatures allowing fireman to flood the battery without additional equipment
Fire and heat proof-ness of battery holes > 5 minutes at 500 °C (open flame)
Reliable corrosion protection and sealing against water ingress
Excellent puncture resistance
Secure adhesion to steel, aluminum, plastics, painted substrates, and reinforced plastic substrates in automotive lightweight constructions

Application Fields

During battery assembly tesa® 54485 Fireman Access is applied to the inside of the battery housing. Whilst normal operation it securely seals the fireman access hole against water and dust. In case of fire in the battery pack the hole covering patch reliably shields the passenger compartment from fire and heat of the cells for 5 minutes. During fire in the pack (after 5 minutes) or the vehicle tesa® 54485 opens at high temperatures and ensures easy access for the fireman to flood the battery to safely extinguish it without additional equipment.

Backing material	glassfibre / PET film
Color	white
Colour of liner	white
Total thickness	9,690 µm
Type of adhesive	modified acrylic
Type of liner	PE-coated paper

Puncture resistance	1,000 N
Conformability	medium
Temperature resistance	very good
Humidity sealing	very good

Adhesion to steel	12 N/cm

Puncture resistance acc. tesa® J0PM0232, measured from backing side 24 h after application at room temperature:

Test climate = 23 ± 1 °C/ 50 ± 5 % relative humidity
Substrate = e-coated panel, 0.7 mm thickness and hole diameter of 30 mm
Patch diameter = 50 mm Pin diameter = 20 mm
Pressurization = 4 kg roll, 5 x back and forth
Test speed = 300 mm/min

We support your individual application process with tesa designed dispensing solutions to ensure a quick and reliable sealing of holes in battery. By fitting your robot with the best end arm tooling we enable a smart automation concept in your production site.

tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.

Downloads

Download the files below for more technical details and information on this product.

Product information_tesa® 54485_en-SG 63.7 kB

Contact us

Thank you for your message.

We will contact you as soon as possible.

Something went wrong. Please try again later.

Product comparison

Name of product	tesa® 54485 Fireman Access	tesa® 54338PV0	tesa® 54337 PV1	tesa® 54339 Low VOC	tesa® 54718 Paintable Noise Blocker	tesa® 54337 PV1	tesa® 54335 PV0 PunctureGuard	tesa® 6042PV0TL ProSeal	tesa® 54657 Low VOC	tesa® 54657	tesa® 54657 Low VOC
Total thickness	9,690 µm	95 µm	450 µm	260 µm	1,350 µm	450 µm	990 µm		290 µm	290 µm	290
Type of adhesive	modified acrylic	modified acrylic	tackified acrylic	modified acrylic	modified acrylic	tackified acrylic	modified acrylic		thermosetting natural rubber	thermosetting natural rubber	thermosetting natural rubber
Backing material	glassfibre / PET film	PET film	PVC film	PET film	polyolefin	PVC film	PET		Acrylic-coated cloth	Acrylic-coated cloth	Acrylic-coated cloth
Color	white	transparent	black	transparent	grey	black	grey	colourless	grey	grey	grey
