tesa® 4943
Product details and specifications
Product Construction
Backing material | non-woven |
---|---|
Color | translucent |
Colour of liner | white |
Thickness of liner | 120 µm |
Total thickness | 100 µm |
Type of adhesive | tackified acrylic |
Type of adhesive (covered side) | tackified acrylic |
Type of liner | PE-coated paper |
Product Construction
Backing material | non-woven |
---|---|
Color | translucent |
Colour of liner | white |
Thickness of liner | 120 µm |
Total thickness | 100 µm |
Type of adhesive | tackified acrylic |
Type of adhesive (covered side) | tackified acrylic |
Type of liner | PE-coated paper |
Properties / Performance Values
Elongation at break | 2 % |
---|---|
Tensile strength | 9 N/cm |
Ageing resistance (UV) | good |
Static shear resistance at 23°C | good |
Tack | good |
Temperature resistance short term | 100 °C |
Humidity resistance | good |
Chemical resistance | medium |
Static shear resistance at 70°C | good |
Fogging | good |
Temperature resistance long term | 70 °C |
Static shear resistance at 40°C | medium |
Properties / Performance Values
Elongation at break | 2 % |
---|---|
Tensile strength | 9 N/cm |
Ageing resistance (UV) | good |
Static shear resistance at 23°C | good |
Tack | good |
Temperature resistance short term | 100 °C |
Humidity resistance | good |
Chemical resistance | medium |
Static shear resistance at 70°C | good |
Fogging | good |
Temperature resistance long term | 70 °C |
Static shear resistance at 40°C | medium |
Adhesion to Values
Adhesion to ABS (initial) | 6.6 N/cm |
---|---|
Adhesion to ABS (after 14 days) | 7.1 N/cm |
Adhesion to Aluminium (initial) | 3.6 N/cm |
Adhesion to Aluminium (after 14 days) | 4.2 N/cm |
Adhesion to PC (initial) | 7.7 N/cm |
Adhesion to PC (after 14 days) | 7.1 N/cm |
Adhesion to PET (initial) | 4.6 N/cm |
Adhesion to PET (after 14 days) | 5.4 N/cm |
Adhesion to PS (initial) | 6.9 N/cm |
Adhesion to PVC (initial) | 6.1 N/cm |
Adhesion to PVC (after 14 days) | 10.8 N/cm |
Adhesion to Steel (initial) | 5.5 N/cm |
Adhesion to Steel (after 14 days) | 8.1 N/cm |
Adhesion to Values
Adhesion to ABS (initial) | 6.6 N/cm |
---|---|
Adhesion to ABS (after 14 days) | 7.1 N/cm |
Adhesion to Aluminium (initial) | 3.6 N/cm |
Adhesion to Aluminium (after 14 days) | 4.2 N/cm |
Adhesion to PC (initial) | 7.7 N/cm |
Adhesion to PC (after 14 days) | 7.1 N/cm |
Adhesion to PET (initial) | 4.6 N/cm |
Adhesion to PET (after 14 days) | 5.4 N/cm |
Adhesion to PS (initial) | 6.9 N/cm |
Adhesion to PVC (initial) | 6.1 N/cm |
Adhesion to PVC (after 14 days) | 10.8 N/cm |
Adhesion to Steel (initial) | 5.5 N/cm |
Adhesion to Steel (after 14 days) | 8.1 N/cm |
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
