tesa® 65611 InvisiBond One Lift Cold

One-time removable foam tape for solid surfaces and cold temperature - 1.100µm double sided

Product description

InvisiBond One Lift Cold (tesa® 65611) is a double-sided PE foam tape equipped with a PET reinforcement film. It consists of a versatile adhesive with well-balanced performance on the open side. The end-user side is specifically designed to fit assembly in cold environments.

Our double-sided PE foam tapes are primarily characterized by its ability to compensate irregular surfaces, enabling high bonding power even on rough surfaces and an excellent shock absorption.
The main disadvantage of conventional foam tapes becomes apparent when they have to be removed: Visible foam residue remains on the substrate, which is time-consuming and costly to remove.
The newly developed InvisiBond One Lift Cold (tesa® 65611) brings an end to foam residue thanks to its unique product design: The PET reinforcement film enables undesirable foam residues to be removed quickly, easily and completely. The noticeable results for our customers are significant time and cost savings.
Additionally, the liner-side adhesive, being dedicated to the end-user, is fit for cold temperature bonding. This enables this product to be used in e.g. refrigerated display cases.

InvisiBond One Lift Cold (tesa® 65611) features:
  • PET reinforcement film to allow quick, easy and complete removability of foam residue
  • Versatile adhesive for high initial and ultimate bonding power even on critical substrates (covered-side)
  • Special adhesive for secure bonding in cold environments (open-side)

Application Fields

InvisiBond One Lift Cold (tesa® 65611) is especially suitable for customers that want to remove bonded parts from non-delaminating surfaces without leaving behind unsightly foam residue. Example mounting applications include but are not limited to:

  • Bonding in refridgerated display cases
  • Price label strips (shelf edge strips, shelf label holder, etc.)
  • POS displays
  • Exhibition sample displays
  • Temporary signage
  • Decorative elements for furniture

Product Construction

Type of adhesive acrylic
Total thickness 1100 µm
Backing material PE foam
Color white

Properties / Performance Values

Elongation at break 100 %
Static shear resistance at 23°C good
Chemical resistance good
Humidity resistance very good
Tack good
Ageing resistance (UV) good
Static shear resistance at 40°C good
Softener resistance medium

Adhesion to Values

Adhesion to Steel (initial) 13 N/cm
Adhesion to Aluminium (covered side, initial) 4.5 N/cm
Adhesion to PVC (covered side, initial) 4.5 N/cm
Adhesion to Aluminium (after 14 days) 13 N/cm
Adhesion to PVC (initial) 6 N/cm
Adhesion to Steel (covered side, after 14 days) 13 N/cm
Adhesion to Alu (covered side, after 14 days) 13 N/cm
Adhesion to Aluminium (initial) 13 N/cm
Adhesion to PVC (covered side, after 14 days) 13 N/cm
Adhesion to Steel (after 14 days) 13 N/cm
Adhesion to Steel (covered side, initial) 4.5 N/cm
Adhesion to PVC (after 14 days) 13 N/cm

Additional Info

Liner variants:
  • PV0 brown glassine paper (71 µm)

Peel Adhesion:
  • Immediately: foam splitting when bonded to open side on Steel, Aluminium
  • After 14 days: foam splitting on Steel, Aluminium, PVC
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
