tesa® 62580

Hydrophilic film for IVD products


Product description

tesa® 62580 is a transparent PET film functionalized on one side with a non-adhesive hydrophilic coating.

tesa® 62580 features:

1 Fast and reliable fluid flow

1 Proven compatibility with many enzymes

1 Excellent aging stability

1 Reliable bonding of the hydrophilic side to tesa spacer tapes

1 Proven performance and integrity of multi-layers with tesa spacer tapes after aging


Product details and specifications

Application Fields

Securing fluid flow in capillary cell in-vitro diagnostic applications.
Backing material PET film
Color transparent
Thickness of tape 100 µm
Type of adhesive functional
Contact Angle 20 °
Wetting Index 36
Storage and handling instructions:

Shelf life: 48 months from date of coating.
Avoid contact with water, material is sensitive against hunidity. Protect against mechanical impacts.

tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
Downloads

Download the files below for more technical details and information on this product.

Get in contact with us!

Contact us

Thank you for your message.

We will contact you as soon as possible.

Something went wrong. Please try again later.

Product comparison

Name of product tesa® 62580 tesa® 4156 PV1 tesa® 7946 tesa® 7475 PV2 tesa® 60402 tesa® 65610 InvisiBond One Lift tesa® flameXtinct 45020 Differential tesa® 58335 150µm D/S PET tesa® 58334 100µm D/S PET tesa® Printer's Friend 4863 PV3 tesa® 58374
Type of adhesive
functional
natural rubber
pure acrylic
acrylic
acrylic
tackified acrylic
FR acrylic
tackified acrylic
tackified acrylic
natural rubber
tackified acrylic
Backing material
PET film
cellophane
PETP
PVC foam
PE foam
PET
PET
PET
Silicone-coated cloth
PET
Total thickness
50 µm
56 µm
1,600 µm
1,200 µm
190 µm
150 µm
100 µm
620 µm
100
Temperature resistance short term
200 °C
80 °C
200 °C
Adhesion to Steel (after 14 days)
4 N/cm
10.5 N/cm
9.7 N/cm
9.5 N/cm
Adhesion to Aluminium (after 14 days)
4 N/cm
9.5 N/cm
Adhesion to PVC (after 14 days)
4 N/cm
