tesa® 58374

tesa® 58374


Product description

tesa® 58374 is a transparent 100µm double-sided flame retardant PET tape.


Product details and specifications

Application Fields

  • Mounting in power battery olamination application required additional flame retardant property.
Backing material PET
Color transparent
Colour of liner white with tesa logo
Thickness of liner 69 µm
Total thickness 100
Type of adhesive tackified acrylic
Type of liner glassine
Temperature resistance long term 125 °C
Temperature resistance short term 200 °C
Static shear resistance at 23°C good
Dielectric breakdown voltage 6,000 V
Adhesion to Aluminium (initial) 7.3 N/cm
Adhesion to Glass (initial) 6.5 N/cm
Adhesion to Glass (covered side, initial) 7.4 N/cm
Adhesion to PET (initial) 8.5 N/cm
Adhesion to Steel (initial) 8.2 N/cm
Adhesion to Steel (after 14 days) 9.5 N/cm
This tape has especially been developed for power battery demanding mounting, lamination and converting application with flame retardant property as an added value. Due to its non-flammable property it is particularly designed to meet power battery automobile requirement.
Main features:
  • Flame retardant UL94 VTM-0 equivalent
  • Excellent initial bonding to polar substrate (Steel, Al, etc)
  • Good reliability performance
  • Good die cutting ability for converting process
  • Halogen-free
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
Downloads

Download the files below for more technical details and information on this product.

Get in contact with us!

Contact us

Thank you for your message.

We will contact you as soon as possible.

Something went wrong. Please try again later.

Product comparison

Name of product tesa® 58374 tesa® 58335 150µm D/S PET tesa® 58334 100µm D/S PET tesa® 58372 tesa® 58377 tesa® 58375 tesa® 58360 tesa® 58362 tesa® 76565 Bond & Detach tesa® 58323 tesa® flameXtinct 45020 Differential
Total thickness
100
150 µm
100 µm
50 µm
50
100
500 µm
75 µm
190 µm
Type of adhesive
tackified acrylic
tackified acrylic
tackified acrylic
tackified acrylic
FR acrylic
tackified acrylic
tackified acrylic
synthetic rubber
tackified acrylic
FR acrylic
Backing material
PET
PET
PET
PET film
PET
PET
PET
none
non-woven
PET
Temperature resistance short term
200 °C
125 °C
Temperature resistance long term
125 °C
125 °C
125 °C
125 °C
70 °C
125 °C
125 °C
125 °C
Static shear resistance at 23°C
good
good
good
good
good
very good
very good
