tesa® 67210 Bond & Detach®

100µm double sided high shock bond & detach with PU backing

Product description

tesa® 67210 is a double-sided mounting tape which can be removed.
tesa® 67210 features:

Thickness: 100µm
Outstanding shock resistance
High tear resistance
Very high bonding strength
Excellent push out resistance
IPX8
Easy removability by stretching the adhesive
The tape can be removed even after a long bonding time
Residue free removability

Product details and specifications

Application Fields

Battery mounting
Permanent mounting of components in electronic devices with the option to remove the parts for repairing or recycling
Temporary fixation of components

Backing material	PU film
Color	white
Colour of liner	transparent
Total thickness	100 µm
Type of adhesive	specialty
Type of liner	PET

Temperature resistance long term	60 °C
Temperature resistance short term	90 °C
Static shear resistance at 40°C	very good

Adhesion to Aluminium (initial)	5 N/cm
Adhesion to Aluminium (after 14 days)	5 N/cm
Adhesion to Magnesium (initial)	6 N/cm
Adhesion to Magnesium (after 14 days)	6 N/cm
Adhesion to PE (initial)	5 N/cm
Adhesion to PE (after 14 days)	5 N/cm
Adhesion to Steel (initial)	6.5 N/cm
Adhesion to Steel (after 14 days)	6.5 N/cm

tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.

Downloads

Download the files below for more technical details and information on this product.

Product information_tesa® 67210_en-SG 41.6 kB

Contact us

Thank you for your message.

We will contact you as soon as possible.

Something went wrong. Please try again later.

Product comparison

Name of product	tesa® 67210 Bond & Detach®	tesa® 70680 Bond & Detach®	tesa® 77010 Bond & Detach®	tesa® 70620 Bond & Detach®	tesa® 70425 Bond & Detach®	tesa® 64825 Bond & Detach®	tesa® 77015 Bond & Detach®	tesa® 70410 Bond & Detach®	tesa® 70430 Bond & Detach®	tesa® 70420 Bond & Detach®	tesa® 70440 Bond & Detach®	tesa® 70499 Bond & Detach®
Total thickness	100 µm	800	100	200 µm	250 µm	250 µm	150 µm	100 µm	300 µm	200 µm	400 µm	1,000
Type of adhesive	specialty	specialty	specialty	specialty	specialty	synthetic rubber	specialty	specialty	specialty	specialty	specialty	specialty
Backing material	PU film	none	stretchable specialty	none	none	stretchable specialty	stretchable specialty	none	none	none	none	none
Temperature resistance short term	90 °C	90 °C	90 °C	90 °C	90 °C	90 °C	90 °C	90 °C	90 °C	90 °C	90 °C	90 °C
Temperature resistance long term	60 °C	60 °C	60 °C	60 °C	60 °C	60 °C	60 °C	60 °C	60 °C	60 °C	60 °C	60 °C
Static shear resistance at 40°C	very good	very good	very good	very good	very good	very good	very good	very good	very good	very good	very good	very good
Static shear resistance at 23°C		very good	very good	very good	very good	very good	very good	very good	very good	very good	very good	very good
