tesa® 60250

tesa® 60250 30 μm double sided high appearance quality electrically conductive woven tape

Product Features

Superior appearance quality
Excellent electrical conductivity
Good bonding strength

Product description

tesa® 60250 is a gray double-sided electrically conductive self-adhesive tape. It consists of an electrically conductive woven backing and an electrically conductive acrylic adhesive

Product details and specifications

Product Features

Superior appearance quality
Excellent electrical conductivity
Good bonding strength

Application Fields

Grounding in OLED display module
Grounding where appearance needs to be controlled during processing

Backing material	conductive woven
Color	grey
Colour of liner	white
Thickness of liner	50 µm
Total thickness	30 µm
Type of adhesive	conductive acrylic
Type of liner	PET film

Contact resistance z-direction (initial)	0.05 Ohm / square inch
Release of liner	easy
Surface resistance x-y-direction (adhesive)	0.2 Ohm / square

Adhesion to Steel (initial)	5 N/cm
Adhesion to Steel (after 14 days)	7.8 N/cm

tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.

Downloads

Download the files below for more technical details and information on this product.

Product information_tesa® 60250_en-SG 71.3 kB

Contact us

Thank you for your message.

We will contact you as soon as possible.

Something went wrong. Please try again later.

Name of product	tesa® 60250	tesa® 60257	tesa® 60260	tesa® 60381	tesa® 60255	tesa® 60362	tesa® 60251	tesa® 60261	tesa® 60382	tesa® 60372	tesa® 60264
Total thickness	30 µm	250 µm	35 µm	50	150 µm	50 µm	55 µm	25 µm	50 µm	50 µm	17 µm
Type of adhesive	conductive acrylic	conductive acrylic	conductive acrylic	conductive acrylic	conductive acrylic	conductive acrylic	conductive acrylic	conductive acrylic	conductive acrylic	conductive acrylic	conductive acrylic
Backing material	conductive woven	conductive woven	conductive non-woven	conductive woven	conductive woven	conductive woven	conductive woven	conductive non-woven	conductive non-woven	conductive non-woven	conductive non-woven
Adhesion to Steel (initial)	5 N/cm	4.8 N/cm	4 N/cm	8 N/cm	4.5 N/cm			4 N/cm	8 N/cm	4.3 N/cm	3.5 N/cm
Adhesion to Steel (after 14 days)	7.8 N/cm	10.8 N/cm	4.2 N/cm	10 N/cm	10.5 N/cm	8 N/cm		5.6 N/cm	10 N/cm	5.6 N/cm	4.5 N/cm
Contact resistance z-direction (initial)	0.05 Ohm / square inch	0.05 Ohm / square inch	0.02 Ohm / square inch	0.06 Ohm / square inch	0.05 Ohm / square inch	0.01 Ohm / square inch	0.05 Ohm / square inch	0.02 Ohm / square inch	0.06 Ohm / square inch	0.01 Ohm / square inch	0.02 Ohm / square inch
Surface resistance x-y-direction		0.2 Ohm / square	0.2 Ohm / square	0.3 Ohm / square	0.2 Ohm / square	0.1 Ohm / square	0.2 Ohm / square	0.2 Ohm / square	0.3 Ohm / square	0.1 Ohm / square	0.2 Ohm / square

Last updated on 5 Jul 2024
