tesa® 8857
50µm double sided translucent non-woven tape
Product description
tesa® 8857 is made from special tackified acrylic adhesive system which has excellent high temperature resistant property, ideal for demanding FPC mounting applications.
The acrylic adhesive gives this product an excellent temperature resistance up to 260°C. The highly comfortable ultra thin non-woven backing and highly temperature resistant release liner ensures it can be easily released without adhesive residue left or liner broken after reflow oven process.
Key features of tesa® 8857:
1 High temperature resistance with sufficient holding power and peel strength even after solder reflow process
1 High tensile strength, good repulsion resistance
1 Excellent die-cutting properties and very low oozing due to special backing
1 High conformability for uneven surfaces
1 High aging resistance
1 Conforming to RoHS
Product details and specifications
Application Fields
Product Construction
Backing material | ultra thin non-woven |
---|---|
Color | translucent |
Colour of liner | white |
Thickness of liner | 86 µm |
Total thickness | 50 µm |
Type of adhesive | tackified acrylic |
Type of liner | heat resistant paper |
Weight of liner | 100 g/m² |
Product Construction
Backing material | ultra thin non-woven |
---|---|
Color | translucent |
Colour of liner | white |
Thickness of liner | 86 µm |
Total thickness | 50 µm |
Type of adhesive | tackified acrylic |
Type of liner | heat resistant paper |
Weight of liner | 100 g/m² |
Adhesion to Values
Adhesion to ABS (initial) | 4.8 N/cm |
---|---|
Adhesion to ABS (after 14 days) | 6 N/cm |
Adhesion to Aluminium (initial) | 4.5 N/cm |
Adhesion to Aluminium (after 14 days) | 5.9 N/cm |
Adhesion to PC (initial) | 5.8 N/cm |
Adhesion to PC (after 14 days) | 6.9 N/cm |
Adhesion to PET (initial) | 5 N/cm |
Adhesion to PET (after 14 days) | 5.4 N/cm |
Adhesion to PI (initial) | 5.9 N/cm |
Adhesion to PI (after 14 days) | 6 N/cm |
Adhesion to Steel (initial) | 5.3 N/cm |
Adhesion to Steel (after 14 days) | 6.5 N/cm |
Adhesion to Values
Adhesion to ABS (initial) | 4.8 N/cm |
---|---|
Adhesion to ABS (after 14 days) | 6 N/cm |
Adhesion to Aluminium (initial) | 4.5 N/cm |
Adhesion to Aluminium (after 14 days) | 5.9 N/cm |
Adhesion to PC (initial) | 5.8 N/cm |
Adhesion to PC (after 14 days) | 6.9 N/cm |
Adhesion to PET (initial) | 5 N/cm |
Adhesion to PET (after 14 days) | 5.4 N/cm |
Adhesion to PI (initial) | 5.9 N/cm |
Adhesion to PI (after 14 days) | 6 N/cm |
Adhesion to Steel (initial) | 5.3 N/cm |
Adhesion to Steel (after 14 days) | 6.5 N/cm |
Download the files below for more technical details and information on this product.
